China Factory Supply Foton 4*2 10000-15000 Litres Street/Road Water Mist Sprinkler

FOB Price

US$ 20,000 - 50,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Drive Wheel	4x2	Fuel	Diesel
Transmission Type	Manual	Condition	New
Emission Standard	Euro 3
Engine Capacity	4 - 6L	Tank Volume	10001 - 15001L
Dimensions (L x W x H) (mm)	780024203100	Brand Name	JDF
Place of Origin	Hubei, China	Model Number	BJ5163ELFFA
Gross Vehicle Weight	15800	Certification	ISO CCC
After-sales Service Provided	Overseas service center available

1,Sprinkling width>14m.
2,Tank capacity:10000-15000 litres.
3,Engine :136hp.
4,CCC and ISO.

FOTON 10000-15000 Litres Water Tank Truck

Summary Hot line( 0086-18727938399 Fax: 0086-0722-3330262
Basic Information
Vehicle name	Water TRUCK		Chassis:			BJ5163ELFFA
Outline size(L×W×H) (mm)	780024203100		Cargo inline size(L×W×H)(mm):			/
Rating mass(kg)	9550		Empty mass(Kg):			6055
Full mass(kg)	15800		Emission standard			Euro 3
Engine Information
Model	ISDe185 30		Type		6 Cylinder Diesel engine
Power/displacement(KW/ML)	136(185HP)/6700		Manufacture		Cummins
Chassis Information
Wheelbase(mm):	4000		Axle load(kg)		5800/10000
Tire	9.00-20,9.00R20,10.00-20,10.00R20		Max speed (km/h)		90
Front suspension(mm)	1365		Rear suspension(mm)		2010
Front track(mm)	1900		Rear track(mm)		1800
Approach angel(°)	20		Departure angle(°)		10
Steering	Power steering		Brake		Air brake
Cabin	3
Special function
Tank capacity(m³)	10000-15000L	Tank material		Carbon steel
Trade terms
Quote Lifetime	30workdays (we promise the quote is effective in the lifetime!)
Payment terms	1. 30% by T/T in advance, 70% by T/T against the copy of Bill-of-Lading. 2. Letter of credit payment for some countries and regions.
Deliver time	10workdays for LHD , 20workdays for RHD after receive 30% earnest money
MOQ	1set
Supply quantity	3000sets/month
Package	waxing

Note:

1.All the data above is for reference ,we keep the right to improve our product.

2..Price will be changed depending on the exchange rate and amount.
