Tactile Control Panel Switch

Specifications

Tactile Control Panel Switch are manufactured to provide absolute reliability, even in the most hostile of operating environments. Advantages:

 1. The materials for manufacturing Control Panel are obtained from leading manufacturers including Autotype, GE Plastics and 3M.
2. Shenzhen Lunfeng Nameplate Co.,Ltd can provide a wide range of options, both in regard to material and finish.
3. All Membrane Switch panel assemblies are completed in a clean room environmentand can incorporate a variety of sub panel materials including aluminium, plastic, metal dome and poly dome.
4. To ensure customer satisfaction, specialised equipment is utilised to fully test every Membrane Switch control panel.

Type of switch:

1.Tactile membrane Control panel switch

2.Non-tactile membrane switch panel
3.Water-resistance membrane switch panel
4.El membrane switch panel
5.LED membrane switch panel

Specifications:

 Maximum circuit rating: 35V DC, 100mA

• Insulation resistance: ≥100MΩ, 250V DC
• Dielectric withstand: 250VRms, 50 - 60Hz, 1 min
• Contact bounce: ≤5ms
• Life expectancy: 1 million closures
• Operating temperature: -20°C - + 80°C
• Storage temperature: -40°C - + 85°C
• Operating humidity: ≤98% 240hours
• Connector type: 8 pins
• Mount type: adhesive
• Keypad dimensions: 70 x 77 x 8mm
• Cable length (inc connector): 90mm
• Weight: 7g

Notice: We have the capacity to provide you membrane switches with other special requirements, such as water proof, Shielding, Windows/Lens Coating, Embedded LEDs, UV glossy/ matte/ textured, etc.
