7 inch capacitive touch screen for MID

Specifications

Capacitive touch panel touch screen technology solutions have been applied more and more to industries, applications, products and services, such as tablet PC, MID, smart phone, car GPS, Medical device, car DVD, PDA, MP5, MP4, learning machine, dictionary, PSP, consumer electronics, moderate to harsh Machine Control, Process Control, System Control/Office Automation and Car PC, etc.

Shenzhen Lunfeng Technology Ltd. Advantage:

1. Established in 1995, have nearly 16 years production experience in the industry

2. Quality Control (IQC, OQC, ISO9001:2008 and 5S)

3. High quality & Favorable price & Prompt Delivery
5. Small Orders Accepted
6. Superior R&D Background (continuously new product development and current product improvement)
7. Customize Design / Production (OEM/ODM business and flexible designs for customers' special requirements)

We can produce customized projected Capacitive Touch Panel for you. If you have interest, welcome to send the specific inquiry to the bottom message box. We will send back price and more details for your ref. Look forward to have a chance to serve you.

Customized specifications-2.2" ~19" available :

Capacitive touch screens are available in different sizes from 2.2" to 19". Such as 2.8", 3.5", 3.6", 3.7", 4.0", 4.2", 4.3", 4.4', 4.5', 4.7", 4.8", 5.0",5.1", 5.2", 5.6", 5.7", 6.0", 6.2", 6.5", 7.0", 8.0", 8.9", 9.0", 9.7", 10.1",10.4",12.1",15"...

Capacitive touch panel Structure Available:

• G+G
• G+F
• G+F+F
• P+G...

Capacitive Touch Panel Features:

Driving Voltage:   3.3V/5.0V DC                          Surface Hardness: 7H
Transmittance:  Film to Glass >85%                Working temperature: -10°C ~ +60°C
                              Glass to Glass >87%             Storage Temperature: -20°C ~ +70°C
Resolution: 7680*5120                                        Operating Pressure:  < 10g
Data Refreshing Rate: 60Hz
Glass Thickness:0.55mm,0.7mm,1.1mm,2.0mm
Multi-touch: a maximum of 10-point output at the same time available.
Glass Type: Common Glass, Tempered Glass
