Hydraulic Excavator

FOB Price

USD $8,888 - $8,888 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Topmac
Model Number	60	Condition	New
Moving Type	Crawler Excavator	Operating Weight	6000kg
Bucket capacity	0.18m3	Maximum Digging Height	3950mm
Maximum Digging Depth	3750mm	Machine Weight	6000kg
Max Digging Radius	6255mm	Certification	iso9000/ce
After-sales Service Provided	No overseas service provided

Our watchword is surviving on quality, developing on innovation and make best profit for clients. Our company already met ISO900

A. Overall height	2645mm
B. Overall length	6160mm
C. Track overall width	2000mm
D. Track shoe width	450mm
E. Upperstructure ground clearance	740mm
F. Minimum ground clearance	360mm
G. Center to center(idler to sprocket)	2100mm
H. Track overall length	2715mm
I.	3150mm
J. Backfill blade height	360mm
M. Tail swing radius	1700mm
Working weight	6000kg
Ground pressure	30KPa

PERFORMANCE SPECS
A. Maximum dig radius	6255mm
B. Dig radius at groundline	6105mm
C. Maximum dig depth	3720mm
D. Dump height	3950mm
E. Overall reach height	5790mm
F. Bucket rotation	170°
G. Vertical straight wall dig depth	3215mm
H. Lift above groud	385mm
J. Drop below groud	450mm
K.	2610mm
Arm digging force	37KN
Bucket digging force	27KN
BUCKET
Width	Capacity	Weight
668mm	0.18 m³	150kg
