ST/STC SERIES SINGLE-PHASE OR THREE-PHASE A.C SYNCHRONOUS ALTERNATOR GENERATOR

Specifications

High quality ST/STC SERIES SINGLE-PHASE

OR THREE-PHASE A.C SYNCHRONOUS

ALTERNATOR

Advantages:

1.outstanding performance
2.reliable quality
nvenient maintenance

Specification

MINGUAN MOTORS

This series generator are to be used in town, countryside, worksites, mountain and pasture as electric power source for lighting purpose, it can also be used as reserved power source for emergent case using. The generators are of drip proof with rotary field type and adopt harmonic excitation system, easy operation and maintenance. The generators are three-phase, four-wire type, adopting star connection with neutral point. The rated line voltage is 400V, phase voltage 230V, frequency 50Hz. Power factor 0.8(lag). We can provide 60Hz and the other voltage’s generator according to the customer’s request. They can be coupled with a prime mover directly or through v-belt making right or reverse continuous rotation at the rated speed. When the rotation speed of prime mover change 3% or so and load varies in the range of 0~100%cos 0.8~1.0, the generators offer constant voltage, when sudden change (increase or decrease) of load, the generator will soon return to their normal working state, at the same time, without any starting device the generator can directly start an unloaded squirrel cage induction motor.
