Home > Products > LED Pixels Modules String > 30mm ws2811 led modules Milky or Transparent waterproof IP67 DC 12V Led pixel modules Diameter
30mm ws2811 led modules Milky or Transparent waterproof IP67 DC 12V Led pixel modules Diameter
USD $0.4 - $1
/ Piece
20 Pieces(Min.Order)
- T/T Credit Card
You May Like
-
30mm USC1903 led modules Milky or Transparent waterproof IP67 DC 12V Led pixel modules Diameter
-
30mm USC1903 led modules Milky or Transparent waterproof IP67 DC 12V Led pixel modules
-
newest clear lens cover housing ucs1903 ws2811 ws2801 LPD6803 DMX512 30mm led pixel light
-
clear lens cover housing ucs1903 ws2811 ws2801 LPD6803 DMX512 30mm led pixel light
-
ucs1903 ws2811 LPD6803 DMX512 30mm led pixel light
-
ucs1903 ws2811 ws2801 LPD6803 DMX512 30mm led pixel light
Product Details
| Type | LED Bar Lights | Working Temperature(℃) | -30, 40 | |
| Working Lifetime(Hour) | 50000 | Lamp Body Material | PVC | |
| Certification | CCC, CE | Emitting Color | Other, Full color | |
| Place of Origin | Guangdong, China | Brand Name | BTF-Lighting | |
| Model Number | D30-3FCW-WS2811 | Input Voltage(V) | DC12V | |
| LED Light Source | Epistar |
Product Description
Applications:
1.The excellent light and user-friendly designs make LED Pixel perfect for numerous applications, i.e cove
lights, back lights, Night Club lighting,Dance floor ceiling ,outdoor signage
2.They can be a good choice for lights for hotels, restaurants, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers,etc
Detailed information for 30mm pixel led
| Suggested Uses | Color Changing Signs Video Walls Costumes Christmas Lights Building Outline Hallways Other Lighting Effects Night Clubs Bars Home Theater Rooms Window Displays | ||
| Led Color | RGB pixel digial | ||
| Length Of Strip | modules are every +/- 4.5" on center | ||
| Type of LED | 1x RGB Led / Module | ||
| Viewing Angle (Degrees) | 110°-180° deg | ||
| Mounting Options | Double Sided Tape, Ceiling Mount, Wall Mount | ||
| Waterproof Rating | IP-67 | ||
| Voltage | 12v | ||
| Wattage | 0.72 watts per module (60mA) | ||
| Power Usage Watts / Foot: Rated (Actual) | x Watts/Foot | ||
| Number Of Chanels | 3 DMX Channels/Pixel | ||
| Connections Input/Output | Red = 5v (+) White= ADI Green = Data Blue = 5v (-) | ||
| Max Connected Strip Length From Each Power Connection | you should supply aditional power every 50 modules | ||
| Controllable By | DMX to WS2811 Decoder or Digital SD Card Controller | ||
| Lumens | 9 lm/pixel | ||
| Product Size (L)x(W)x(H) | drill bit size .47" (12mm). max matt thickness .18" (5mm) total hight .91" base .84" (21.5 mm) x .79" (20 mm) | ||
| Strip Width | base width 0.84" (21.5 mm) | ||
| Strip Thickness | base length 0.79" (20 mm) | ||
| Comes With | if you order individual modules they will have 2" wire on both sides of the module | ||
