China Glass Cutting Machine-CNC Waterjet Cutting Machine

Specifications

China Glass Cutting Machine-CNC Waterjet Cutting Machine

1- CNC Cross-Axis Water Jet Cutting Table

A- Bed guarantees a best stability and no any shake or distortion ever with a high speed operation;

B- No space ball bearing screw and linear guide;

C- Z axis driven by electric motor;

D- Handy integrated lubricated system provides a simple and esay maintenance;

E- Special designed protecting system guarantees a long using life of the equipment;

F- There are 1.0mx1.2m, 2.0mx1.4m, 2.5x1.4m, 2.0mx1.0m, 2.5x1.8m, 3.0mx1.8m, 4.0x1.8m for choosing.

 China Glass Cutting Machine-CNC Waterjet Cutting Machine

Cutting Specification

   China Glass Cutting Machine-CNC Waterjet Cutting Machine

2- ULTRA-HIGH PRESSURE SYSTEM

A- Controlled by PLC;

B- Bigger Attenuator,stable pressure;

C- There are Air Cooling and Water Cooling to be chosen.

   China Glass Cutting Machine-CNC Waterjet Cutting Machine

Technical Data

   China Glass Cutting Machine-CNC Waterjet Cutting Machine

3- NUMERICAL CONTROL SYSTEM.

A- LE SOFTWARE

It runs on WINDOWS XP system and has many advanced functions such as auto-cuttingin and out, auto nesting,simulating

the track before working, calculating the cutting time and the cost;

 B- Window XP waterjet soffware The design is user-friendly;

 C- Pc-base name brand industrial computer, G-code style controller;

 D- Simple electric design, PLC control;

 E- Quickly show a tool path, avoid wrong cutting;

 F- Add up HP time;

 G- Automatic shown the length of cutting. Easy to caculate the price of cutting for customer;

 H- You can set X.Y axis travel sot spacing. Avoiding cutting head exceed the travel;

 I- You can set servio motor start frequency;

 J- The system can auto generate thd CNC processing program;

 K- Commine AutoCAD drawing with technique data;

 L- Achieve the communication between PC and CNC.

 China Glass Cutting Machine-CNC Waterjet Cutting Machine

4- SUPERCHARGER ( SUPPER INTENSIFIER)

A- Advanced & Reliable Electron-shift;

B- 60,000 PSI Ultra-high Pressure;

C- ESL HP Sed.

--------------------------------------------------------------------------------

   China Glass Cutting Machine-CNC Waterjet Cutting Machine
