Steel Spiral Spring Making Machine for Pen

FOB Price

US$ 35,000 - 39,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Taiwan, China		Brand Name	CHIEN YU
Model Number	CNC-26		After-sales Service Provided	Engineers available to service machinery overseas

Steel Spiral Spring Making Machine for Pen

Model	CNC-26 Spring Coiling Machine
Wire Diameter	0.8 mm ~ 2.6 mm
Max. O.D.	50 mm
Max. Production Speed	300 pcs/min
Feed Length	Unlimited
Feed Speed	135 m/min
D/d	4
Feed (Y) Axis (kw)	2.0kw
Cam (X) Axis (kw)	2.0kw
Monitor Display	Color / Chinese / English
Max. Value	X : 359.99 Y : 99999.99 mm
Min. Value	X : 0.01 Y : 0.01 mm
Memory	999 Programs Max. 250 Lines for each program
Machine Dimensions	142 x 100 x 173 cm
Wooden Case Dimension	194 x 140 x 194 cm
Machine Weights	950 Kgs
Gross Weights	1300 Kgs
Power	220V 3P 50/60Hz

Wire Diameter suitable for 0.8~ 2.6mm.
Max O.D. up to 50 mm.
2-axis control, for wire feed and pitch mechanism.
High precision equipped with CNC controlled servo-motion system
High production speed Max. up to 350 pcs/min..
Simplified setup and program with English/Chinese platform.
Capable of various kind of springs such as compression springs, oil seal springs, taper springs, battery springs and so on.

One Set Tools + User Manual
