CNC-1622 Best Selling Automatic High Speed Cutting Machine

FOB Price

US$ 26,500 - 30,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Taiwan, China		Brand Name	CHIEN YU
Model Number	CNC-16		After-sales Service Provided	Engineers available to service machinery overseas

CNC-1622 Best Selling Automatic High Speed Cutting Machine

Model	CNC-16 Spring Coiling Machine
Wire Diameter	0.4mm ~ 1.6 mm
Max. O.D.	45 mm
Max. Production Speed	400 pcs/min
Feed Length	Unlimited
Feed Speed	150 m/min
D/d	4
Feed (Y) Axis (kw)	2.0kw
Cam (X) Axis (kw)	2.0kw
Monitor Display	Color / Chinese / English
Max. Value	X : 359.99 Y : 99999.99 mm
Min. Value	X : 0.01 Y : 0.01 mm
Memory	999 Programs Max. 250 Lines for each program
Machine Dimensions	138 x 98 x 168 cm
Wooden Case Dimension	194 x 140 x 194 cm
Machine Weights	850 Kgs
Gross Weights	1180 Kgs
Power	220V 3P 50/60Hz

Wire Diameter suitable for 0.4~ 1.6mm.
Max O.D. up to 45 mm.
2-axis control, for wire feed and pitch mechanism.
High precision equipped with CNC controlled servo-motion system
High production speed Max. up to 400 pcs/min..
Simplified setup and program with English/Chinese platform.
Capable of various kind of springs such as compression springs, oil seal springs, taper springs, battery springs and so on.

One Set Tools + User Manual
