stainless steel sanitary 2pc flange pneumatic butterfly-type ball valve

 Specification

The ball valve and plug is the same type of valve. Its closing piece is a sphere, which around the center line of a rotary valve to achieve the valve opening and closing. Stainless steel ball valve in the pipeline is mainly used to make cut, distribution and change the direction of media flow is widely used in recent years as a new type of valve.

The advantages: small fluid resistance, the resistance coefficient and the length of the pipe with the same, simple structure, small size, light weight, strong and reliable. The current ball valve sealing surface material widely used plastic, sealing in a vacuum system has also been widely used. Easy to operate, opening and closing rapidly, from fully open to fully closed as long as the rotation 90 °, to facilitate the remote control. Widely used in chemical, petroleum, power, pharmaceuticals, beer, food, dairy beverage, cosmetics, water treatment and other fields.

 Structure: straight/tee,manual/pneumatic/electrical

 Disk: T/L/Straight type

 Standard: DIN 3A SMS ISO IDF DS

Size: 1 / 2 "-4", DN10-DN100

Max pressure: 16bar/230Psi

Material: ASTM T304/316L, 1.4301/1.4404

Highest temperature: 150 ℃ / 302 ℉ meet the CIP / SIP

 Product show

 Packaging and delivery

   Trade show

 Certification

Wolong

    Fujian Wolong Pipe &Valve Manufacturing Co., Ltd. manufactures stainless steel sanitary fluid valves, pipes and fittings. Based on fine technology background and resources, the company designs and produces 3A, SMS, DIN, BS, AS, DS, ISO, IDF, BPE and RJT sanitary standard pipe fittings and industrial standard pipe fittings to meet customers demands fully. Its rich technology experience and consistent quality style ensure each pipe fitting in line with FDA and GMP requirements.
