2016 new type magnetic liquid separator
- Qingdao
You May Like
-
High efficiency magnetic iron separator for ceramic slurry
-
a new generation magnetic extractor for Aluminium paste
-
Sand magnetic separator /liquid magnetic separator for sale
-
Stainless steel powder blender
-
Top quality CE certified stainless V type powder mixer machine
-
Factory price spiral feeding machine for sale
Product Details
Place of Origin | Henan, China | Brand Name | senyou | |
Model Number | MQN-4 | After-sales Service Provided | No overseas service provided |
Product Description
Specifications
magnetic liquid separator
1.High magnetic filed gradient and intensity.
2. Easy to operate
3.No manual operation.
4.Stable performance and long service life.
2016 new type magnetic liquid separator
Product Introduction
Used for :recycling, timber industry, mining, ceramics, chemical, food and other works, is suitable for size 3 mm below the magnetite, pyrrhotite, roasted ore and ilmenite wet magnetic separation of materials, also used in coal, non-metallic mineral, building materials and other materials in addition to iron, is the industry one of the most widely used, high commonality models.
Suitable material : size 3 mm below the magnetite, pyrrhotite, roasted ore, titanium ore, coal, nonmetalliferous ore and other materials
Feature
1.High-intensity magnetic filed :high gradient magnetic filed,and the highest working magnetic filed intensity can reach 18000~20000 Gauss.
2.High quality magnetic material:the properties of magnetic material above N50 is nummber one in De-ironing industry ,the magnetic material has long use time, and demagnetization rate is less than 3% in 5 years.
3.Well-know spare parts:
A.Water pump use SHIMGE Pumps that is a large listed company in pump industry,if it is damaged within 3 years,you can change a new one for free .
B.Solenoid valves are made by AirTAC
C.Connect hose is made in Italy,it is much durable.
D.The material of pipes is all 304 stainless steel,the SUS304 can not bring two pollution to your material.
E.Using the visual Tablet PC control panel, can be set time according to the actual requirements of iron removal, back to the pulp, washing time .
4.Strong iron removal:the efficiency of the iron magnetic material that the mesh size is more than 200 mesh is up to 98%,it can effectively improve the quality and whiteness of the body.
5.Automatic controlling: automaticly wash iron impurities, to achieve human-machine interaction, continuous work is available
6.Low energy consumption:reducing the production costs.
Technical Parameters
Model | Rated Voltage | Rated Power | Magnetic field intensity | Processing Capacity | Dimension (mm) | Weight |
MQN-4 | 380V | 0.5KW | 18000GS | 20-25T/H | 1700*1500*1600 | 1750KG |
MQN-6 | 380V | 0.5KW | 18000GS | 35-45T/H | 1700*2200*1600 | 2500KG |
Product Details
Application
2016 new type magnetic liquid separator is most useful for wet mineral separation of such materials as magnetite, pyrrhotine, roasted ore and ilmenite, etc. And it is also applicable for iron removal working of such materials as coal, nonmetal and building materials, etc.
Our Permanent Magnetic Separator is especially widely used in architectural pottery factory,craft ceramics factory ,bathroom industry, etc.
Packaging
Export wooden case
Waterproof,anti-corrosion,difficult to burn,sturdy and durable.
Delivery Detail
Adequate stock,delivery in 10~15 days after payment.
Assured services system
1.Pre-Sales Service: Free consultancy and design advices as requested,the most suitable solution based on demands.
2.After-Sales Service: Senyou provide 12 months guarantee and free service for first time commissioning and training up customers`engineer.
3.Emergency Services: if you are located within 1000 kilometers in domestic,Senyou under take to arrive at the spot in 48 hours after receiving reports;if you are not,72 hours services would be served.
4.Spare Parts Supply: In order to offer the timely services,Senyou has set up a number of warehouses and services offices.We will keep enlarging offices and keep spare parts available in stock for soonest supply to customers.
5. 24-hour Online Services : Contact us online if you have any questions.
