XCMG GR8250C 250HP Model Motor Grader With Shanghai Diesel Engine ZF Transmission Hot for Exporting

FOB Price

US$ 58,800 - 78,800 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Forward Speed(km/h)	38
Reverse Speed(km/h)	25	Place of Origin	Shandong, China
Brand Name	SDLG-VOLVO	Model Number	G8180C
Weight	15800KGS	Dimension(LWH)	8815X2640X3450
Certification	CE GOST	After-sales Service Provided	Overseas service center available

250HP,With shanghai kate diesel engine or cummins engine,ZF6WG180 Gearbox,electrical control,front dozer,rear ripper.GOST,CE.

G8250C Motor Grader

USD118,800USD PER UNIT FOB CHINA PORT.

Warranty:1800 working hours or 18monthes which come first.

Packing:one unit into one 40HQ container.

Model				G8250C
Basic Specification	Engine Model			Shanghai SD diesel engine.
	Rated Power/Speed		kw/rpm	138/2200 140/2300
	Dimension		mm	8900x2625x3470
	Operating Weight		kg	15400
Performance Specification	Travelling Speed, Forward		km/h	5,8,11,19,23,38
	Travelling Speed, Reverse		km/h	5,11,23
	Tractive Force		KN	79
	Max. Grade ability		%	20
	pressure		Kpa	260
	Working Hydraulic Pressure		Mpa	18
	Transmission Pressure		Mpa	1.3~1.8
Operating Specification	Max. Steering Angle for Front Wheels		°	±50
	Max. Lean Angel of Front Wheels		°	±17
	Max. Oscillation Angel of Front Axles		°	±15
	Max. Oscillation Angle of Balance Box		°	front and rear 5
	Frame Articulation Angle		°	±27
	Min. Turning Radius		m	7.3
	Blade	Max. Lift Height	mm	450
		Max. Cutting Depth	mm	500
		Max. Blade Position Angle	°	90
		Blade Cutting Angle	°	28-70
		Circle Reversing Rotation	°	360
		Moldboard Width*Height	mm	3965x610

FRONT DOZER:+3000USD. REAR RIPPER:+3000USD.
