Copper Conductor Energy Cable, Twin and Earth 2.5mm2 PVC Wire
- Xingang
 - T/T Credit Card PayPal

You May Like
-


High Quality Solid Copper Conductor Building Wire, House Wiring (BV Cable)
 -


House Wiring Electric Cable
 -


Insulated Type and Solid Conductor Type Copper Wire and Cable
 -


Copper Conductor Material and PVC Insulation Material Lighting Cable Braided
 -


Wholesale PVC Insulated 3 Core 2.5mm Electric Cable
 -


PVC Insulation Material and Solid Conductor Type CCA Conductor Power Cable

Product Details
| Place of Origin | Hebei, China | Brand Name | Ronghua | |
| Model Number | BV BVR BVVR RVV | Type | Insulated | |
| Application | Other, construction, in-door,lighting | Conductor Material | Other, Copper or Tinned copper | |
| Conductor Type | Other, Solid or Stranded | Insulation Material | PVC |
Product Description
copper conductor energy cable, twin and earth 2.5mm2 PVC Wire
Hebei Ronghua Wire And Cable Co,.LTD-- Solid or Stranded bare or tinned copper conductor PVC insulated electric cable wire

The Details of Electric cable wire
1. Rate Voltage: 300/500V, 450/750V
2. Max. working temperature: 70 °C , can be 90 °C ,105 °C as requirement
3. Insulation: PVC
4. Conductor:  Class 1/2 Plain annealed copper wires,solid or stranded

5.Cross Section Areas: 0.75mm2~185mm2
6. Remark: Flame retardant,fire resistance,low smoking and Halogen free,or other property can be avaliable
7. Packing: 100m per roll, or as your request.
The Application of electrical wire
Single Core PVC insulation Copper Conductor house wiring electical wire cable is used for general purpose, as building wire for power, lighting and control wire to electrical appliances, suitable for use in conduit and for fixed, protected installation.

Technical Data of electric wire cable
Nominal section (mm2)  | Number/diameter of core (mm)  | Maximum outer diameter (mm2)  | Reference weight (Kg/km)  | Conductor resistance at 20°C ≤(Ω/km)  | ||
copper  | aluminum  | aluminum  | copper  | |||
1.5(A)  | 1/1.38  | 3.3  | 20.3  | -----  | -----  | 12.1  |
1.5(B)  | 7/0.52  | 3.5  | 21.6  | -----  | -----  | 12.1  |
2.5(A)  | 1/1.78  | 3.9  | 31.6  | 17  | 11.80  | 7.41  |
2.5(B)  | 7/0.68  | 4.2  | 34.8  | -----  | -----  | 7.41  |
4(A)  | 1/2.25  | 4.4  | 47.1  | 22  | 7.39  | 4.61  |
4(B)  | 7/0.85  | 4.8  | 50.3  | ------  | -----  | 4.61  |
6(A)  | 1/2.76  | 4.9  | 65  | 29  | 4.91  | 3.08  |
6(B)  | 7/1.04  | 5.4  | 71.2  | ----  | ----  | 3.08  |
10  | 7/1.35  | 7.0  | 119  | 62  | 3.08  | 1.83  |
16  | 7/1.70  | 8.0  | 179  | 78  | 1.91  | 1.15  |
25  | 7/2.04  | 10.0  | 281  | 118  | 1.20  | 0.727  |
35  | 7/2.52  | 11.5  | 381  | 156  | 0.868  | 0.524  |
50  | 19/1.78  | 13.0  | 521  | 215  | 0.641  | 0.387  |
70  | 19/2.14  | 15.0  | 734  | 282  | 0.443  | 0.268  |
95  | 19/2.52  | 17.5  | 962  | 385  | 0.320  | 0.193  |
120  | 37/2.03  | 19.0  | 1180  | 431  | 0.253  | 0.153  |
150  | 37/2.25  | 21.0  | 1470  | 539  | 0.206  | 0.124  |
185  | 37/2.52  | 23.5  | 1810  | 666  | 0.164  | 0.0991  |
240  | 61/2.25  | 26.5  | 2350  | 857  | 0.125  | 0.0754  |

electrical cable wire 10mm Pakage:
100 meters per roll, then PE film, then carton or woven bag. or as customers' request.
Our Advantage:
- More than 30 years experience.
 - OEM & ODM service is acceptable.
 - Good quality with factory price
 - Can print words on the wire

Hebei Ronghua Wire Cable Co,.Ltd is a special manufacture of wire and cables with more than 30 years experience. We are Factory Manufacturing wire and cables, Competitive price, Excellent Quality, Shortly Delivery Time, Kindly Service.
Certifications:

Other related wire and cables:
Q1:When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
Q2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
Q3.How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days.
Q4.What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
If you have any questions of the electrical cable wire , please kindly contact us freely! We will reply you within 12 hours!
