Two Layer co Extrusion Film Blowing Machine, Bag Making Machine,Superior Quality 3 Layer Coextrusion

Product Description This machine set is to satisfy the customer’s requirements of high quality,

high output film blowing equipment.

1.It adopts the extruder with force feeding function, precision type ceramic heater,

   precision type double vents air ring, horizontal type rotary traction system,

   fully automatic surface friction type double cut double winders, computer concentrate control system.

2.Advanced technique and equipments, compare with kindred equipment,

   it has the advantages such as more compact structure, high output,

   better produce quality, less energy consume, easier operation.

3.It can be widely used into various kind of high transparence packing

   film manufacture and create the considerable economic benefit for you.

4.Fully automatic double cut double winders

Optional parts:

• Auto loaderX3pcs
• Chiller
• Corona
• Full automatic winder
• Embossing roller
• collecting material drop

MAIN PARAMETERS

 Model :DS-70

Max folded film width :700mm

Film thickness:0.02-0.12

Output :60kg/h

Raw material:PP,LDPE,LLDPE

Screw dimension:2*45mm

Screw L/D:228:1

Total power of the machine:73kw

Shape size(L*W*H):6.0*1.8*4.0m

Weight :4500kg

Correct specification depend on the actual model all specifications are subject to change without prior  notice

Main performance and features:

1, the use of advanced microcomputer control: control state digital display length, speed, bag number, batch number, etc., in place automatically alarm, and has power protection memory function, set convenient.

2, the use of servo drive stepper motor feeding: feeding stability, uniform tension, to set the length and the actual length of the same bag. And can complete any set of the required length of the bag, the error is small, high accuracy.

3, the use of photoelectric tracking: the color patterns and bag in the right direction, high positioning accuracy, and can be eliminate length deviation of process printing.

4, the main frequency of the main drive with frequency conversion: with over load, over current, over voltage and other automatic protection function.

5, the machine with automatic stop without material equipment, printing equipment, temperature sensor failure automatic parking is not automatic parking equipment. Can be equipped with all kinds of shape punching machine, ultrasonic welding machine.
