XPS Foam Board Extrusion Line

     XPS foamed board production line is one of our new hi-tech products. XPS foamed board is one kind of good insulating materials with continuous even surface and beehive structure. It has superior advantages of good heat preservation, heat insulation, water-proof and high compression resistance. XPS board has been widely used in the fields of heating-preservation and insulation for roof and out-wall, low temperature storage facilities, surface and undersurface of roads. As an ideal insulating and damp-proof material, it has wide market prospect. QINGDAO DEYILI PLASTIC MACHINERY CO. LTD

Main technical parameter:

Model: XPS-100/120
Connection model: Single/Single, Lengthways connection
Screw diameter and L/D ratio: 100-32D Single screw , 120-42D Single screw
Width(mm): 600
Thickness(mm): 20-70
Capacity: 180m3/24h
Power: 55kw, 37kw

Model: XPS-135/150
Connection model: Single/Single, Direct connection
Screw diameter and L/D ratio: 135-32D Single screw , 150-42D Single screw
Width(mm): 600   900   1200
Thickness(mm): 20-120   20-80   20-60
Capacity: 270-350m3/24h
Power: 75kw, 55kw

Model: XPS-170/200
Connection model: Single/Single, Double Tandem
Screw diameter and L/D ratio: 170-30D Single screw , 200-34D Single screw
Width(mm): 600   900   1200
Thickness(mm): 20-150   20-150   20-80
Capacity: 400-450m3/24h
Power: 200kw, 160kw
