Home > Products > XCMG Excavator > XCMG Hydraulic Crawler Excavator XE150D
XCMG Hydraulic Crawler Excavator XE150D
Negotiable
/ Set
1 Set(Min.Order)
- 60 Set / Sets per Month
- Qingdao/Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | XCMG | |
| Model Number | XE150D | Condition | New | |
| Moving Type | Crawler Excavator | Operating Weight | 14400kg | |
| Bucket capacity | 0.61m3 | Maximum Digging Height | 8641mm | |
| Maximum Digging Depth | 5538mm | Machine Weight | 14.4t | |
| Max Digging Radius | 8296m | Rated Speed | 5.2/3.4km/h | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
XCMG Hydraulic Crawler Excavator XE150D
We can supply Road contruction machinery(road roller, paver, cold milling machine, motor grader),
hoisting machinery(truck crane, crawler crane, tower crane, truck mounted crane),
concrete machine(concrete pump, concrete mixer), earth moving machinery
(wheel loader, excavator, backhoe loader, bulldozer), drilling machinery, etc..
Spare Parts for Engine: LOVOL, Weichai, Shangchai, Yuchai
Spare parts for transmission gearbox: ZF, Advance
Spare parts for hydraulic system: pump, pipe, oil cylinder, etc.
Spare parts for Axle: Meritor
and the others.
CONTACT ME TO GET THE VERY DETAILES
Parameter
| Model | Unit | XE150D |
| Operating weight | kg | 14400 |
| Standard bucket capacity | m³ | 0.52-0.61 |
| Engine | ||
| Engine Model | / | 4BTAA3.9 |
| Direct injection | / | √ |
| Four strokes | / | √ |
| Water cooling | / | √ |
| Turbo charged | / | √ |
| Air to air intercooler | / | √ |
| No. of cylinders | / | 4 |
| Rated power/speed | kw/rpm | 85.4/2200 |
| Max. torque/speed | N.m | 447/1500 |
| Displacement | L | 3.927 |
| Main performance | ||
| Travel speed | km/h | 5.2/3.4 |
| Swing speed | r/min | 12.3 |
| Max. gradeability | / | ≥35 |
| Ground pressure | kPa | 38 |
| Max. Bucket digging force | kN | 85 |
| Max.arm crowd force | kN | 65 |
| Max. traction force | kN | 135 |
| Hydraulic system | ||
| Main pump | / | two |
| Rate flow of main pump | L/min | 2×120 |
| Max pressure of prime relief valve | MPa | 31.4/34.3 |
| Max pressure of travel system | MPa | 34.3 |
| Max pressure of swing system | MPa | 25 |
| Max pressure of pilot system | MPa | 3.9 |
| oil & fuel refilling | ||
| Fuel tank capacity | L | 250 |
| Hydraulic tank capacity | L | 130 |
| Engine lubrication | L | 14 |
| Dimensions | ||
| Overall length | mm | 7801 |
| Overall width | mm | 2590 |
| Overall height | mm | 2880 |
| Overall width of upper structure | mm | 2512 |
| Track length | mm | 3660 |
| Overall width of undercarriage | mm | 2590 |
| Crawler width | mm | 600 |
| Track length on ground | mm | 2910 |
| Crawler gauge | mm | 1990 |
| Clearance under counter weight | mm | 964 |
| Ground clearance | mm | 478 |
| Min. tail swing radius | mm | 2325 |
| Working Range | ||
| Max. digging height | mm | 8641 |
| Max. dumping height | mm | 6181 |
| Max. digging depth | mm | 5538 |
| 8inch horizonal digging depth | mm | 5287 |
| Max. vertical wall digging depth | mm | 4727 |
| Max. digging reach | mm | 8296 |
| Min. swing radius | mm | 2335 |
| Angle of arm deflection | Degree | —— |
