XCMG Mini Hydraulic Crawler Excavator XE40

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	XCMG
Model Number	XE40	Condition	New
Moving Type	Crawler Excavator	Operating Weight	4050kg
Bucket capacity	0.14m3	Maximum Digging Height	5317mm
Maximum Digging Depth	3598mm	Machine Weight	4050kg
Max Digging Radius	2385mm	Rated Speed	4.2/2.6km/h
Certification	ISO	After-sales Service Provided	Engineers available to service machinery overseas

XCMG Mini Hydraulic Crawler Excavator XE40
1.Long service life
2.High efficiency ,low fuel consumption

XCMG Mini Hydraulic Crawler Excavator XE40

Model			XE40
Bucket capacity		m3	0.14
Standard bucket width		mm	652
Operation weight		kg	4,050
Dimension (in transportation)	Overall length	mm	5,455
	Overall width	mm	1,650
	Overall height	mm	2,440
	Min. clearance	mm	350
Engine	Model		4TNV88
	Total displacement	L	2.19
	Rated output power	KW/rpm	27.1/2200
Digging performance	Max. digging height	mm	5,317
	Max. dumping height	mm	3,697
	Max. digging depth	mm	3,598
	Max. vertical digging depth	mm	3,330
	Max. digging radius	mm	5,810
	Boom deflection angle	°
	Min. slew radius	mm	2,385
	Min. rear slew radius	mm	1,490
	Bucket digging force	kn	23.2
Track type			Rubber/steel
Track width		mm	300
Travel System	Track length	mm	2,198
	Wheel base	mm	1,721
	Track gauge	mm	1,335
	Travel speed (Gear I/II)	km/h	4.2/2.6
	Gradeability	%	58
Slew speed		rpm	13.5
Bulldozing plate	Bulldozing plate width	mm	1650
	Bulldozing plate height	mm	300
	Lifting distance	mm	267/365
Hydraulic pump type			Variable pump×1 +gear pump×1
Slew motor type			Piston hydraulic motor
Travel motor type			Piston hydraulic motor
Fuel tank capacity		L	65
Hydraulic oil tank capacity		L	70
