Home > Products > Industrial Pumps > AY Series Centrifugal Oil Pump
AY Series Centrifugal Oil Pump
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | BANGPU | |
| Model Number | AY | Theory | Centrifugal Pump | |
| Structure | Single-stage Pump | Usage | Water | |
| Power | Electric | Standard or Nonstandard | Standard | |
| Fuel | Other | Pressure | Low Pressure | |
| Application | Other, Oil |
Product Description
Centrifugal Oil Pump
1. APPLICATION
AY series oil pump is used mainly for petroleum refining,petrochemical and chemical industries to transport the petroleum containing no solid grains, liquefied petroleum gas, other petroleum products, high temperature high pressure, combustible and explosive liquids.
2. FEATURES
Six kinds of structure are available with AY type pump: single-stage single-suction, single-stage dual-suction, dual-stage,single-suction underslung type, single-stage dual- suction and dual-stage single-suction, dual-stage dual-suction both ends supported type.
1) The casing is radial opened, especially suitable for transporting high temperature high pressure and combustible and explosive or toxic liquids. It is mounted with the horizontal central line supported;
2). AY type oil pump uses a flexible diaphragm extended clutch which is easy maintenance without removal of the suck-in or drain-out pipeline.
4. PERFORMANCE:
Item | Data |
| Flow | 6.3---600m3/h |
Head | 33---356m |
Max. Pressure | < 4Mpa |
| Medium Temperature | -45°C---400°C |
5. STRUCTURE DRAWING
