GT optical multi touch screen panel 36inch

FOB Price

US$ 369 - 399 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Products Status	Stock	Screen Size	Other, 32"
Type	Infrared	Interface Type	USB
Resolution	Other, 4096*4096	Brand Name	GreenTouch
Model Number	GT-IR-32	Place of Origin	Guangdong, China

Product Description

Specifications

1.Size:36"
2.CE, FCC, RoHs
3.Long lifetime
4.Water proof
5.Fast delivery

GT-IR multi touch screen 32"

Description

1. Optical touch screen takes the optical and imaging touch technology. It's placed by the cameras on the adjacent corners of the touch screen pass the data of the movement of the surface objects continuously, and it changes the touch position continuously through the movement sensor.

2. The technology combines with the Windows7 OS successfully, which realizes the two points touch more accurately, more fast and more fluently. It guides and promotes the touch application to a new position.

Specification

T-Series Technical Specification
Touch Technology	Optical Imaging
Performance
Resolution(Interpolation)	4096*4096
Ratio	16:9
Linearity Error	1.5mm
Response Speed	<10ms
Mechanical
Input Method	Finger, gloved hand, or opaque object
Touch Times	Unlimited
Touch Activation Force	No minimum touch activation force is required with IR touch technology
Minimum Touch Object	5mm
Environmental suitability
Temperature	Operating: -20°C ~ 70°C
	Storage: -40°C ~ 85°C
Relative Humidity	Operating: 90%(non-condensed at max 40°C)
	Storage: 90%(non-condensed at max 40°C)
Altitude	Up to 3,000m
Life Time	At least 7 years
Electrical
Appearance Color	Standard: Black
Scan frequency	125Hz
Connection interface type	USB 2.0
Output Format	Coordinate output
Touch Accuracy	2MM(Over 90%Area)
Operation Voltage	Typical +DC 5V, +4.75V to +5.25V
Power Supply	USB, power ripple max.200mV rms
Power	<2W, operating current<200mA
Agency Approvals	CE, FCC Class B
Operation current	<180mA
USB Connector Cable	1500mm
Glass	Thickness 4mm
