RO5400 Tantalum bars
- Shanghai Tianjing HK
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Getwick | |
| Model Number | Ta1,Ta2,TaNb3,Ta2.5W etcs | Application | various | |
| Dimensions | Dia(3~120)*Lmm |
Product Description
Specifications
tantalum rodsSize:Dia(3~120)*Lmm
Specification:ASTM B365-98 RO5200,RO5400
Materials:Pure Ta 99.95% --99.99%
Tantalum and Tantalum alloy rod
Size:Dia(3~120)*Lmm
Purity, >=99.95% or 99.99%
Material,RO5200, RO5400, RO5252(Ta-2.5W), RO5255(Ta-10W)
Standard,ASTM B 365-98
Chemistry ppm | ||||||||||||
Designation | Chief component | Impurities maxmium | ||||||||||
Ta | Nb | Fe | Si | Ni | W | Mo | Ti | O | C | H | N | |
Ta1 | Remainder | 300 | 40 | 30 | 20 | 40 | 40 | 20 | 150 | 40 | 15 | 20 |
Ta2 | Remainder | 800 | 100 | 100 | 50 | 200 | 200 | 50 | 200 | 100 | 15 | 100 |
TaNb3 | Remainder | 35000 | 100 | 100 | 50 | 200 | 200 | 50 | 200 | 100 | 15 | 100 |
TaNb20 | Remainder | 170000- 230000 | 100 | 100 | 50 | 200 | 200 | 50 | 200 | 100 | 15 | 100 |
Ta2.5W | Remainder | 400 | 50 | 30 | 20 | 30000 | 60 | 20 | 150 | 50 | 15 | 60 |
Ta10W | Remainder | 400 | 50 | 30 | 20 | 110000 | 60 | 20 | 150 | 50 | 15 | 60 |
Tolerance
Diameter | Diameter Tolerance | Length | Tolerance | |||
forging rod | Extruded Rods | rolling rod | ground rod | |||
3.0-4.5 | ±0.05 | - | ±0.05 | - | 500-1500 | + 5 |
>4.5-6.5 | ±0.10 | - | ±0.10 | - | 500-1500 | + 5 |
>6.5-10.0 | ±0.15 | - | ±0.15 | - | 400-1500 | + 5 |
>10-16 | ±0.20 | - | ±0.20 | - | 300-1200 | + 5 |
>16-18 | ±1.0 | - | - | ±0.30 | 200-2000 | + 20 |
>18-25 | ±1.5 | ±1.0 | - | ±0.40 | 200-2000 | + 20 |
>25-40 | ±2.0 | ±1.5 | - | ±0.50 | 150-4000 | + 20 |
>40-50 | ±2.5 | ±2.0 | - | ±0.60 | 100-3000 | + 20 |
>50-65 | ±3.0 | ±2.0 | - | ±0.80 | 100-1500 | + 20 |
Tantalum rods and alloy rods are primary used in corrosion resistant industry, nuclear station, tantalum capacitors, electronics, etc
