Home > Products > Paper Cutting Machine > WD-520H Heavy Duty Hydraulic Paper Cutting Machine
WD-520H Heavy Duty Hydraulic Paper Cutting Machine
US$ 1 - 9,999
/ Piece
1 Piece(Min. Order)
- ningbo
- T/T Credit Card PayPal
You May Like
-
WD-720R Heavy Duty Hydraulic Paper Cutting Machine
-
Professional Manufacturer 430mm Electric China Paper Cutter
-
Professional Manufacturer 475mm (WD-4810) Precise Paper Cutter
-
(WD-4300) Manual Paper Cutter 430M Manual Paper Guillotine
-
Professional Manufacturer 480mm Manual Paper Cutting Machine
-
Heavy -duty Good Cutting Precision Hydraulic Paper Cutting Machine ( WD-670H)
Product Details
| Condition | New | Type | Paper Cutting Machine | |
| Computerized | Yes | Place of Origin | China | |
| Brand Name | WD | Model Number | WD-520H | |
| Voltage | 220v/110v± 10% 50Hz(60Hz) | Power(W) | 1.8kw | |
| Dimension(L*W*H) | 1280*1010*1430mm | Weight | 400kg | |
| Certification | CE Certificate | Warranty | 1 Year | |
| After-sales Service Provided | No overseas service provided |
Product Description
Model: WD-520H Heavy Duty Hydraulic Paper Cutting Machine
Max. Cutting Width: 520mm
Min. Cutting length: 30mm
Max Cutting Thickness: 80mm
Cutting Precision: ± 0.2mm
Pressing Paper Mode : Hydraulic + Mechanical Pedal
Cutting Paper Mode: Hydraulic
Pushing Page Mode: Program-control, Automatic
Program: Yes, 20cuts*100 programs
Display : Touch Screen
Power : 220v/110v± 10% 50Hz(60Hz) 1.8kw
Machine Weight: 400kgs
Machine Size: 1280*1010*1430mm
Main features:
1. Heavy-duty frame design, precision machining, cutting accuracy in accordance with professional standards.
2. Work table adopts industrial grade floating bead, with high durability and make pushing paper flexibly, solve the problem of paper underlying into pushing paper table.
3. Knife carrier is hanging arm structure.
4. Use low voltage electrical control system, select international brands OMRON PLC system.
5. Use well-known brands WEINVIEW touch screen display, easy to operate.
6. Mechanical foot pedal device do clamping paper and alignment, easy, reliable and safe.
7. Clamping and cutting are using double hydraulic design, stable and powerful.
8. The machine is with three operating modes: CNC, program-controlled and segmented, can be metric conversion.
Touch screen
20 cuts each program
Main features:
1. Heavy-duty frame design, precision machining, cutting accuracy in accordance with professional standards.
2. Work table adopts industrial grade floating bead, with high durability and make pushing paper flexibly, solve the problem of paper underlying into pushing paper table.
3. Knife carrier is hanging arm structure.
4. Use low voltage electrical control system, select international brands OMRON PLC system.
5. Use well-known brands WEINVIEW touch screen display, easy to operate.
6. Mechanical foot pedal device do clamping paper and alignment, easy, reliable and safe.
7. Clamping and cutting are using double hydraulic design, stable and powerful.
8. The machine is with three operating modes: CNC, program-controlled and segmented, can be metric conversion.
Touch screen
20 cuts each program
