1700 C Atmosphere Controlled High Precision Tube Furnace
- QINGDAO TIANJIN SHANGHAI
- T/T PayPal
You May Like
-
2015 New 3 Zone Multi-function Lab Electric Tube Furnace/CVD Electric Furnace
-
1700 C Laboratory Small Metal Annealing Furnace
-
1200c Mini Desktop Furnace for Lab
-
High Precision Atmosphere Controlled Single Zone Electric Furnace Machine
-
Three Zone Multi-function Lab Electric Heating Furnace
-
Digital Control Vertical Hardening Furnace for Lab
Product Details
| Brand Name | CY | Model Number | CY-T1700-60IC |
Product Description
1700 C atmosphere controlled high precision tube furnace
Application of high precision tube furnace
1.CVD experiment
2.Preparation of carbon nanotubes
3.Growth of graphene
4.Crystalline silicon substrate coating
5.Diffusion welding for metal materials
6.Heat treatment under the vacuum of atmosphere surroundings
Features of high precision tube furnace
1.Fast heating rate:20°c/min
2.Multi-function: CVD experiment, growth of graphene, crystalline silicon substrate coating and etc
3.LED high light display
4.50 steps programmable automatic control
5.Can connect with vacuum pump and atmosphere furnace.
6.Accept PC interface control
Technical parameters of high precision tube furnace
| Model | CY-T1700-60IC |
| Display | LCD touch screen |
| Chamber material | imported fiber |
| Heating element | imported alloy heating wire |
| Max.temperature | 1700℃ |
| Working temperature | ≤1600℃ |
| Heating rate | ≤20°c/min |
| Heating zone | Single |
| Temperature zone length | 300mm |
| Thermostatic zone length | 150mm |
| Tube Material | high purity corundum |
| Tube Size | 100mm 80mm 60mm 50mm for option |
| Tube length | 1000mm |
| Flange connection | stainless steel flange |
| Control mode | PID automatic control via SCR power control |
| Temperature accuracy | ±1℃ |
| Working voltage | AC 220V 50-60Hz |
| Main power | 4.5kw |
| Packing | PLYwood box |
| Thermal couple | B type |
| Accessories | corundum tube 1pc, flange 1set, plug 4pcs,O-rings 8pcs, glove 1pair, alumina crucible 1set, furnace hook 1pc, manual book |
Picture of high precision tube furnace
Packaging of high precision tube furnace
PLY wood box as below picture, or as customer request.
Shipping and transportation
As customer request. Generally, Our mode of transport are as by sea, by air or rail transport
Payment
T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC
Warranty
Main product is 15 month, except wearing parts.
