Home > Products > melting furnace > 1700c High Temperature Programmable Small Melting Furnace

1700c High Temperature Programmable Small Melting Furnace

FOB Price

US$ 6,090 - 50,090 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	CYKY		Model Number	CY-M1700-AOR
Place of Origin	Henan, China

1700c high temperature programmable small melting furnace

Product Description

Featrues of small melting furnace

1.Bottom mouth feed, elevating type
2.Aluminium fiber, resistance high temperature 1700 ℃
3.Programmable and PID automatic control
4.LCD touch screen

5.Heating temperature uniform , less burning, metal components uniform

6.Portable structure, light weight, high efficiency, energy saving

7.Furnace can be electric or manual dumping, easy to discharge, particularly suitable for casting

Technical parmaters of small melting furnace

Model	CY-M1700-AOR
Display	LCD touch screen
Max. temperature	1700°C
Working temperature	≤1650°c
Heating rate	Suggestion 10°C/min
Temperature accuracy	±1°C
Inside chamber	120120120mm
Heating zone	single
Heating element	1850 type heating rod
Thermal couple	B Type
Chamber material	alumina fiber
Temperature control	PID automatic control via SCR power control
Heating curves	50 steps programmable
Sealed method	open cover
Working temperature	AC 220V 50-60Hz
Accessories	sensor 1 pc, glove 1pair, crucible tongs 1pc, crucible 3pcs, manual book

Pictures show of small melting furnace

Packaging & Shipping

Packaging of small melting furnace

wooden box outside ,and filled with polyfoam, plastic paper indide .OR as below picture show. or as customer request.

Our Services

Payment

T/T, L/C, WEST UNION, PAYPAL, ESCROW AND ETC

Warranty

Main product is 12 month, except wearing parts.

Wearing parts as below:

Door stopper, glove, crucible tongs,crucible, bearing board.
