Home > Products > Wheel Alignment > High Accuracy 3d Wheel Alignment, 3d Wheel Aligner John Bean
High Accuracy 3d Wheel Alignment, 3d Wheel Aligner John Bean
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China |
Product Description
3d wheel alignment
3d wheel aligner john bean system
High Accuracy
Competitive and high quality
Features:
1. High precision and Real- time measurement results.
2. Reference 3D virtual plane for measuring the vehicle, faster and more accurate.
3. Four standard targets, no electronic spare part and the cable, easy maintaining.
4. The targets no need to charge, no need level and no Influenced by the temperature.
5. Advanced software enables the imaging cameras to automatically adjust their height when the vehicle is raised or lowered and allowing the technician to perform adjustments at a comfortable working height.
6. Space saving and mobile.
Technical Data:
Item | Accuracy | Range |
Individual toe | ±5° | ±0.02° |
Total Toe | ±10° | ±0.02° |
Camber | ±15° | ±0.01° |
Caster | ±20° | ±0.04° |
King-pin inclination angle | ±25° | ±0.04° |
Set Back | ±10° | ±0.02° |
Thrust angle | ±10° | ±0.02° |
Ride Height* Measurement
· Measure right height and obtain proper alignment specifications for those vehicles requiring it
· Measure manually or use the Target Imaging Pointer
Secure Clamping Without Touching the Rim
· Only the tire is contacted
· Clutch limited clamping force ensures accurate and repeatable results
· Durable and lightweight magnesium construction
