Product Details
| Brand Name | CYKY | Model Number | CY-CF1200 | |
| Place of Origin | Henan, China |
Product Description
1200C laboratory Crucible muffle Furnace
Brief introduction of the crucible furnace:
CY-CF1200 series crucible Furnace are the most effective high temperature furnace, Furnaces are made with high quality alumina fiber brick. They are designed with double shell with fan cooling which can make temperature raising quickly but keep outside similar as door temperature. Furnace temperature is controlled by high precision SCR digital controller with accuracy ±1'C an 30 sements programmable.
Specification of the high temperature crucible furnace :
Feature | CY-CF1200 vacuum well-type crucible type compacted the control system and furnace chamber. The furnace chamber is molding by vacuum absorb technical, the resistance wire is embedded. The large diameter quartz tube, with the vacuum sealing flange ensure to heat the sample under the condition of vacuum or kind of atmosphere. | |
Parameter: | Part Number | CY-CF1200 |
Chamber Size | Φ210×340 mm | |
Work Temp. | ≤1100℃ | |
Max. Temp. | 1200℃ | |
Temp. Control Mode | 30 segment programmable control | |
Heating Rate | 20℃/min | |
Accuracy | ±1℃ | |
Structure | Up-door open type | |
Voltage | AC220V | |
Power | 3KW | |
Diemension | 510×435×425mm(L×W×H) | |
Weight | 35Kg | |
Display of the high temperature crucible furnace:
Zhengzhou CY Scientific Instrument Co., Ltd.- is a high and new technology enterprise registered in Zhengzhou,Henan province. Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in researching and developing, designing and manufacturing of equipment used in scientific researches.
Our mainly products include high temperature furnace and heating element, like lab muffle furnace, tube furnace, dental furnace, vacuum furnace,gold melting furnace, SiC heating element, MoSi2 heating element, alumina tubes and crucibles, and etc.
