stainless steel piezoelectric types of industrial vibration sensors

FOB Price

US$ 200 - 400 / Piece

1 Piece(Min. Order)

Port shanghai/ningbo
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	TENLEE
Model Number	TL151A,152A,252A,153A	Usage	Vibration Sensor
Theory	Other, piezoelectric	Output	Other, voltage,charge

Product Description

1. Industrial Accelerometers introduction

Industrial accelerometers are rugged, stainless steel vibration monitoring sensors for predictive maintenance applications. All Our sensors are hermetically sealed , case isolated, laser welding sealing, waterproof, prevent oil design; Suitable for the industrial field environment under long-term stable and reliable work;

151A series industrial condition monitoring accelerometershave passed Intrinsic safety certified;

151A series can provide 4 to 20 mA output; Low noise, strong anti-jamming capability;

152A/252Aseries Low cost ,suitable for permanent installation and long-term on-line monitoring;

153A series :low excitation voltage (low to 5 VDC) IEPE accelerometer, suitable for hand-held vibration Meter with battery power supply;

2.Specifications

Model	Sensitivity	Frequency Range (±10%)	Measuring Range	Resolution	Operating Temperature	Weight	Output Type	Mounting Type	Size
151A100D	100mV/g	0.5Hz to 6kHz	±50g	0.5mgrms	-40 to +121℃	80Gram	MIL-C-5015 2core	M6 1/4-28 Optional	Φ22X45mm
151A100C	100mV/g	0.5Hz to 6kHz	±50g	0. 5mgrms	-40 to +121℃	130Gram			23X35X25mm
151A500D	500mV/g	0.2Hz to 2kHz	±10g	0.15mgrms	-40 to +121℃	90Gram			Φ22X51mm
151A500C	500mV/g	0.2Hz to 2kHz	±10g	0.15mgrms	-40 to +121℃	130Gram			23X35X25mm
252A25	25pC/g	0.5Hz to 5kHz	±2,000g	N/A	-54 to +150℃	37Gram	TNC	M5	Φ18X40mm
252A100	25pC/g	0.5Hz to 5kHz	±2,000g	N/A	-54 to +150℃	51Gram	TNC		Φ18X40mm
152A100	100mV/g	0.5Hz to 8kHz	±50g	0.5mgrms	-40 to +121℃	32Gram	TNC		Φ18X40mm
153A100	100mV/g	0.5H to 8kHz	±15g	0. 5mgrms	-40 to +121℃	32Gram	2-pin		Φ18X40mm

3. Packaging
