WANTE BRAND WT10-15 full automatic egg laying brick block making machine delivering to Mexico
- 30 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
WT10-15 egg laying block making machine,egg laying concrete block machine
-
WT10-15 mobile hollow block making machine,saudi arabia mobile concrete block making machine price
-
2015 Trade Assurance WT10-15 germany automatic cement block making machine price
-
QT40-3B brick laying machine,hand press brick making machine
-
WT6-30 Egg laying automatic concrete block making machine
-
WT6-30 10000 blocks per day/cement block making machines price
Product Details
Condition | New | Type | Hollow Block Making Machine | |
Brick Raw Material | Concrete | Processing | Brick Production Line | |
Method | Hydraulic Pressure | Automatic | Yes | |
Capacity | 12000Pcs/day | Place of Origin | Shandong, China | |
Brand Name | Wante | Model Number | JMQ10-15 | |
Voltage | 380V | Power | 16kw | |
Dimension(L*W*H) | 3150*1800*2400mm | Certification | CE&ISO9001:2008 | |
Warranty | one yaer | After-sales Service Provided | Engineers available to service machinery overseas |
Normal export package.
Product Description
WANTE BRAND WT10-15 full automatic egg laying brick block making machine delivering to Mexico
WT10-15 is a fully automatic mobile block making machine of very high productivity. Working together with a mobile palletizing machine, it is possible to make the process of production and packing of elements fully mechanized. Optional superpressing and high frequency vibration functions ensures optimisation of raw materials consumption and increases product quality.
This is a type of „egg-laying” machine which means that it moves on a concrete flat floor and shapes and leaves the fresh formed elements behind it.
Thanks to easy exchange of moulds it is possible to produce wide range of different elements. For example: hollow blocks, ceiling, floor blocks, solid blocks, kerb stones, lawn borders.
Technical data | |
Overall dimension | 3150*1800*2400mm |
Demold method | Hydraulic |
Turning method | Hydraulic |
Hydraulic system pressure | 16-20Mpa |
Excitation frequency | 3200Hz |
Total power | 16KW |
Total mass | 4200KG |
Molding cycle | 10-15S |
Molding | 10 Pcs/mould(400*200*200/390*190*190 mm) |
Capacity | 12000Pcs/ 8h |
Types of bricks can be made | 390*240*190/390*190*190/390*115*190 All kinds of moulds can be made by customers' drawings |
Moving method | Automatically move and hydraulic steering |
Excitation way | Three-dimensional box excitation |
Raw material | Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes. |
More details
WANTE BRAND WT10-15 full automatic egg laying brick block making machine delivering to Mexico
Delivery photos
WANTE BRAND WT10-15 full automatic egg laying brick block making machine delivering to Mexico
Company profile
Linyi Wante Machinery Co.,Ltd
Linyi Wante Machinery Co., Ltd has long endeavoured to the research, production and sales of the block making machine,
there is the state-of-the-art equipment, super technology and high standards of test base.
Headquarter: Room1518, kaiyuanshangcheng, No.10 Jinyueshan Road, Linyi, Shandong, China
Office number: +86 539- 8113558
Fax number: +86 539- 8110558
Mobile phone: +86-17853995669
Skype ID: linyidaxue529
QQ: 974515079
Company Profile

Linyi Wante Machinery Co., Ltd. has long engaged in the research, production and sales of block making machines. There is state-of-the-art equipment, superb technology and high-standard test bases. Our company has always been adhering to the "integrity, pragmatism, innovation, development" spirit of enterprise, constantly absorbing domestic and foreign advanced technologies and mature experience. After 10 years of unremitting efforts, we have rapidly developed into a leading enterprise in the industry. Our main products: aerated concrete production lines, concrete block making machines, hydraulic paver block machines, cement pipe machines, widely used in building materials, roads and bridges, energy and others. On the foundation of the domestic market, we focus on the development of international market. Our products have been exported to more than 100 countries and regions, such as Africa, Southeast Asia, the Middle East and South America, with frequent international business dealings. We have established a good market reputation. Our company has a perfect quality management system, and has passed the ISO9001:2000 international quality management system certification. Besides, our company has established our own sales network in many countries around the world, and has set up sales branches and service outlets in major cities across the country. So we are able to provide our clients with timely and convenient service. We adhere to the brand philosophy that "excellence, do first-class products, creating a model for the industry", and enhance the brand ideology of "building the brand quality, service, innovation, positive enterprising, noble professionalism" to drive our company forward to a first-class enterprise.
