GIGA LX cartons folding gluing machine with counter

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Food
Packaging Type	Cartons	Packaging Material	Metal
Automatic Grade	Automatic	Driven Type	Electric
Power	22KW	Place of Origin	Shanghai, China
Brand Name	GIGA LX	Model Number	LX-FG
After-sales Service Provided	Engineers available to service machinery overseas

1:folding gluing machine
2:Component USA famous brand VALCO
3:Stacker output controllable
4:High speed 300sheet/m

LX-FG Automatic Folding and Gluing Machine Inline With Carton Machine

folding gluing machine

Carton folder gluer is full computerized
Touch screen input order, automatic adjust specifications.
Lateral scorer to facilitate folding.
Vacuum suction belt transmission to prevent slipping, and avoid scissors movement.
Both sides equipped with guiding rollers.
Imported USA VALCO glue spraying system, automatic non-contact tracking, and accurate coating.
Carton strapping machine moving parts are composed of imported ball screw and linear guides track;
Stacker and output are controlled by servo motor, max.speed 300 sheet/min.
Work independently or equipped with printer & slotter machine.
Max.machine speed: 300sheet/min.
Max.feeding size: 2500*1600mm
Min.feeding size: 650*400mm
Main motor power: 22kw
Total power: 50.8kw
Dimension: 12000*4810*2530mm
Total weight: 20 ton

1-2.....
