WT1-20 interlocking brick and block dimensions
- 300 Set / Sets per Month
- Qingdao port or any port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
WT1-20 Kenya Clay Brick Laying Machine
-
2016 new technology QT40-3B mobile cement egg laying hollow bricks machine from Linyi wante Machinery
-
2016 QT40-3A movable cement egg laying hollow bricks block machine Supplier's Choice
-
WANTE MACHINERY QT40-3B egg laying small size cement hollow brick making machine
-
QT40-3b mobile hollow cement brick block making machine price nepal cement brick making machine price
-
WANTE BRAND hot sale low price Egg Layer concrete hollow block making machine WT6-30 Supplier's Choice
Product Details
Condition | New | Type | Interlock Block Making Machine | |
Brick Raw Material | Clay | Processing | Brick Molding Machine | |
Method | Hydraulic Pressure | Automatic | No | |
Capacity | 2000-2400pcs | Place of Origin | Shandong, China | |
Brand Name | Wante | Model Number | WT1-20 interlocking machine | |
Voltage | 220v/240v/380v/440v/adjustable | Power | 5.5kw | |
Dimension(L*W*H) | 1080x1080x1400mm | Certification | ISO9001&CE | |
Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Nude package in one container
Plywood package in less than one container
Product Description
1.Hydroform interlocking brick and block dimensions price
1>Hydroform interlocking machine
2>CE&ISO9001:2008
3>Min order:1 set
4>Capacity:2000-2400pcs
5>Warranty:one year
WT1-20 hydroform interlocking machine is our newest soil and cement brick making machine.
it use clay or soil or concrete materials.you can chose diesel enginee or motor.
so it is very good for the placewhere there is no power or electricity.
one machine can produce differnt kinds of interlocking block by changing moulds.
when building ,just lock them together
3. brick and block dimensions parameters
Main specification and technical parameters | |
Overall size | 1080(L)×1080(W)×1400(H)mm |
Shaping cycle | 20seconds |
Power | 5.5KW |
6-8 Hp diesel engine | |
Pressure | 16Mpa |
Total weight | 700 KGS |
brick and block dimensions capacity
Block size | Pcs/mould | Pcs/hour | Pcs/day |
230x220x115mm | 1 | 250-300 | 2000-2400 |
4.Hydroform brick and block dimensions Materials proportion
3.Materials proportion
This is the most popular proportion in making block making machine:
1. cement,clay
Raw Materials | Quantity per piece |
Water | 3% |
Cement | 6-8% |
clay | 80-90% |
Other specify | You can change the proportion depend on your needs. This block is heavy,but strong |
2. Full clay
Raw Materials | Quantity per piece |
Water | 3% |
clay | 90-95% |
Other specify | You can change the proportion depend on your needs. This block is light,but not so strong |
4.Block design and drawing:
...
