Home > Products > Stripe floor tile making machine > KBJX 500*300mm Stripping Machine for Floor Tiles
KBJX 500*300mm Stripping Machine for Floor Tiles
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Type | Tile Forming Machine | |
| Tile Type | Concrete | Use | Floor | |
| Production Capacity | 5-8pcs/min | Place of Origin | Jiangsu, China | |
| Brand Name | KBJX 500*300mm stripping machine for floor tiles | Model Number | KB-125E/500 500*300mm stripping machine for floor tiles | |
| Power(W) | 7.5KW | Voltage | 110-380V | |
| Dimension(L*W*H) | 3460*1830*2750MM | Weight | 7T | |
| Certification | ISO9001 | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
KBJX 500*300mm stripping machine for floor tiles500*250mm
2500-3500pcs per 8 hours
cement + stone powder + cobble stone
KBJX 500*300mm stripping machine for floor tiles
(stripe paver machine, stripe paving making machine, stripe stone machine, stripe block making machine)
Raw material for KBJX 500*300mm stripe paving block machine
Raw materials | Specification | Ratio(kg) | Notes |
Cement | common | 50 |
|
Additive | Water-reducing agent | 0.5~1.0 | optional |
Fly ash | Should be qualified | 10~30 | optional |
Stripe pavers / stripe blocks are made by two machines, tile making machine + striping machine = KB-125E/500 + KB-125TWA
KB-125E/500 specification:
| Equipment type | Model 500 |
| moulding speed | 5-6pcs/min |
| main frame power | 7.5kw |
| main frame weight | 7T |
| external dimension | 3300*1680*2700mm |
KB-125TWA specification:
| External dimension | 3000*880*1580mm |
| Grinding head diameter | Ø338mm |
| Cutter blade diameter | Ø200mm |
| motor power | 21.8KW |
| Equipment | pump or tap water |
| weight | 3.5T |
Total production line picture for KBJX 500*300mm stripping machine for floor tiles
equipments composed for KBJX 500*300mm stripping machine for floor tiles
| 1 | Moulding machine | 1 set |
| 2 | constant feeder machine | 1 set |
| 3 | blender | 1 set |
| 4 | elevator machine | 1 set |
| 5 | air compressor | 1 set |
| 6 | stripping machine | 1 set |
work flow of KBJX 500*300mm stripping machine for floor tiles
Work flow: Elevating--- Mixing --- Fixed-quantity filling --- Pressure forming --- Mould unloading --- Forming tiles --- Onto the tiles shelf ---Maintenance (24 hours) --- Stacking --- Natural maintenance --- Stripping lines --- Finished products.
finished stripes
Multi-functional samples of tiles by chaning mould
