NTAG203 NFC Sticker

FOB Price

Negotiable / Piece

500 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	OEM
Model Number	NTAG203

Product code	NTAG203-D21-3
Product Category	Passive RFID antenna
Antenna Material	Aluminum Al (30μm) + PET (38μm) + Al bridge (10μm)
Chip	NXP NTAG203
Frequency	13.56MHZ
RF Protocol	NFC Forum Tag TYPE 2; ISO/IEC 14443A
Capacity	924 bytes of total memory; 888 bytes of user r/w memory
Working life	100000 times / 10 years
Antenna size	Φ21 mm
Wet inlay	Φ24 mm
Thickness	0.07mm (chip location: 0.23mm)
Weight	0.01g
Working temperature	-20℃ to +60℃
Storage temperature	-25℃ to +65℃
Packing	1000pcs/roll or by customized
Read Distance	up to 1.5~3cm depending on antenna geometry and reader configuration
Shelf life	one year Under the conditions of vacuum packaging,temp 20-30℃/humidity 20%-60%
Application	Smart advertisement, Goods and device authentication, Call request, SMS, Call to action,Voucher and coupons, Bluetooth or Wi-Fi pairing, Connection handover, Product authentication, Mobile companion tags, Electronic shelf labels, Business cards

Handling

Inlays with ink marks are defective, do not use.
RFID Inlays or labels are sensitive product, do not bend or stretch
Static-free bag will be use for packing; always keep environmental static charge to a minimum.
Unico solution reserves the right to modify, change, supplement or discontinue product offerings at any time without notice
All products from Unico Solution should be tested by the customer/user thoroughly to ensure the product meets the particular requirements. Unico Solution does not represent that this product is fit for any particular purpose or use.
