99.5% Alumina Ceramic/Electrical Insulation Pin/Ceramic Insulation Rod/Ceramic Insulator/Thermostat
- Shenzhen
- T/T Credit Card
You May Like
-
Precision Polishing Ceramic Electrical Insulation Pin/ceramic Insulation Rod/ceramic Insulator for Electronic Components
-
Alumina Ceramic Washer/electrical Insulation Washer
-
Good Quality/electrical Insulation Washer/ceramic Washer
-
Industrial Customized Part/electrical Insulation Washer/ceramic Washer
-
High Purity Alumina Ceramic Electric Insulation Washer
-
Mechanical White and Black Alumina Thermal Insulation Ceramic Ring
Product Details
| Place of Origin | Guangdong, China | Brand Name | hxpceramics | |
| Model Number | electrical insulation pin | Type | Insulating Ceramics | |
| Material | Alumina |
Product Description
Specifications
electrical insulation pin-Good insulation
-thermostat ceramic parts
-Used in electric products
99.5% Alumina Ceramic/Electrical Insulation Pin/Ceramic Insulation Rod/Ceramic Insulator/Thermostat
Features:
1) A variety of specifications available.
2) Satisfy various technical request
3) Lower medium spoilage
4) Good insulation performance and high temperature resistance
5) Stiffness texture
6) Used in all electric products and electric heating products
7) OEM, ODM and OBM are welcomed
We can supply the products according to customer's drawings, samples and performance requirement.
Alumina ceramic is kind of structural ceramics, with insulation resistance, voltage resistance, high strength, good thermal conductivity, dielectric loss, stable electrical performance characteristics. Used in electronic ceramic substrates, ceramic electrical insulation, vacuum devices, devices porcelain, spark plugs and other products. We can make the part by hot injection pressing, dry pressing, isostatic pressing and extrusion productive technology etc
| Performance | |||||
| Item | Unit | 95 Al2O3 | 96 Al2O3 | 99 Al2O3 | |
| Physical Characteristics | Bulk density | g/cm3 | 3.6 | 3.6 | 3.9 |
| Water absorption | % | 0 | 0 | 0 | |
| Mechanical Characteristics | Flexural strength | Mpa | 320 | 340 | 360 |
| Hardness Vickers | Gpa | 12.2 | 13.5 | 15.6 | |
| Elastic modulus | Gpa | 280 | 320 | 370 | |
| Poisson’s ratio | - | 0.22 | 0.23 | 0.23 | |
| Thermal Characteristics | Linear expansion coefficient | (200C-5000C) 10-6/0C | 7.1 | 7.2 | 8 |
| Thermal conductivity | w/(m.k) | 16 | 24 | 32 | |
| Specific Heat | *10-3J/(kg*K) | 0.78 | 0.78 | 0.9 | |
| Electrical Characteristics | Dielectric constant (1MHZ) | - | 9 | 9.4 | 9.9 |
| Dielectric loss angle | *10-4 | 15 | 5 | 1 | |
| Dielectric strength | *106V/m | 12 | 15 | 15 | |
