WOLWA Mobile Concrete Mixer Truck 1.2m3 With Hydraulic Self-loading System

Product Introduction

1. Mixing drum capacity 1.7 m3, discharge opening height 1.5 meters
2. Output volume of production capacity: 1.2 m3 / cans, 4.8 cubic meters/hour
3. Wuxisida engine 490 boost, water-cooled, 4 cylinder / 4.836 litres, 48 kw / 2400 RPM
4. Yunnei 490 boost, water-cooled, 4 cylinder / 4.836 litres, 48 kw / 2400 RPM
5. Transmission way full hydraulic pressure drive, 4 wheel drive, wheel steering, domestic axle
6. Walking speed 2 km/hour at low speed, high speed 10-20 km/hour
7. Cab drive on the left, turn, prevent falling object type bridge, the side loading shovel
8. Hydraulic system of domestic hydraulic system, closed loop, used in hydraulic transmission and cylinder rotate
9. Four lever hydraulic electric joystick
10. Bucket 270 litres, hydraulic valve
11. Chute hydraulic adjustment point of view, in order to increase the length of the discharge
12.  Hydraulically driven self-priming pump, washing with high pressure water pump vehicle, electronically controlled self-priming pump, take 100 kg water per minute
13. Barely able to brake brake, the double independent circuits
14. Tire construction machinery tires 12-16.5
15. 24 v power system
16. Diesel oil tank: 35 litres, hydraulic tank: 120 liters
17. Weight 3200 kg
18. Overall dimensions length: 5.6 meters wide, 1.9 meters high, 2.6 meters
19. Measuring electronic weighing, water meter

Specification

Figure Photos

Company Information

Shandong Wolwa Croup Co., Ltd is an advanced technology industry integrating research and development, production and sales. For ten years, Wolwa Group, with the goal of "Forging the first class brand, Being the pioneer of the industry", adheres to scientific and technological innovation, and walks on the way to different development. Relying on its advantage in talent, technology and capital, the Wolwa has also opened a new chapter in high-end equipment manufacturing.
