Adss Cable Hardware From Power Accessories Supplier or Manufacturer
- Qingdao
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Shandong Haihong | |
| Model Number | FD---20 |
Product Description

Brand:Shandong Haihong
Composition: hot galvanized casting iron hammer, hot galvanized steel twisted wire, aluminum
alloy clamp, stainless steel bolts.
Purposes: to eliminate or reduce the vibration when the fiber optic cable operate under the influence of kinds of factor, then protection of cables and fittings.
Features: using a typical Harrow design, the basic principles : dynamic absorbing energy, frequency protection range from 6Hz to 150Hz, and in this range it has four resonant frequencies.
Technical requirements: comply with GB / T 2336-2000 anti-vibration hammer technological conditions.
Order Information: Users must provide the following information for specific projects the company can make corresponding vibration programs:
a. line tower schedule.
b. topography, landforms (plains, hills, mountains, forests, across rivers).
c. Cable specification model and relevant parameters - diameter (mm), nominal tensile strength (N), unit weight (kg / m) and so on.
Damper Specifications Model and Parameter table:
Model | Aluminum clip Specifications | Clamping range (mm) | Total length (mm) | Clamp Length(mm) | Clamp Height (mm) | Quality (kg) |
4D30 | 27 | 27.0-22.5 | 383 | 52 | 70 | 2.5 |
23.4 | 23.4-19.5 | 72 | ||||
20.3 | 20.3-16.5 | 73 | ||||
4D20 | 23.4 | 23.4-19.5 | 330 | 52 | 72 | 1.4 |
20.3 | 20.3-16.5 | 73 | ||||
18 | 18.0-15.0 | 65 | ||||
4D10 | 18 | 18.0-15.0 |
|
| 65 | 1.0 |
16 | 16.0-13.3 | 63 | ||||
14 | 14.0-12.2 | 62 | ||||
Note: 4D10, 4D20, 4D30-type anti-vibration hammer in accordance with applicable cable diameter and select the appropriate size of the aluminum clip. | ||||||
Armor rod for anti-vibration hammer: In order to avoid the damage when anti-vibration hammer clamp gripping the OPGW cable, coupled with aluminum alloy armor rod, protection cable, at the same time the system play a role in anti-vibration .
Specifications Model representation: HXT-Length (mm )-**.
**-- On behalf of Cable diameter (mm).
