Home > Products > Anti-static Turnover Series > PCB ESD Magzine Rack Antistatic Storage Magzine Rack
PCB ESD Magzine Rack Antistatic Storage Magzine Rack
- Shenzhen
- T/T L/C D/P D/A
You May Like
-
Antistatic Pallet ESD Plastic Logistics Pallet
-
No.1 Black Antistatic Plastic Tray ESD Cheap Tray
-
No.2 Black ESD Plastic Tray Antistatic Cheap Tray
-
No.3 Black Antistatic Plastic Tray ESD Cheap Plastic Serving Trays
-
No.4 Black Antistatic Plastic Trays ESD Black Cheap Trays
-
No.6 Black Antistatic Plastic Tray ESD Cheap Tray
Product Details
| Place of Origin | Guangdong, China | Brand Name | CSKJCLEAN | |
| Model Number | CS6683086 | Type | Multi-Level | |
| Material | Stainless Steel | Feature | Esd Protection | |
| Use | Industrial | Certification | Other, RoHS | |
| Depth | 2.0mm | Weight Capacity | 20-25kg | |
| Width | 530mm | Height | 570mm |
Product Description
Product Information: Anti-static rack can quickly dissipate the electrostatic charge on the surface of the material , which can provide the protective potential for the electrostatic charge sensitive components. The baseboard can endure 20kg to 25kg of gravity, with the characteristics of non-deformation, toughness, durability, which is suitable for different size of PCB products, the upright will not be out of shape when the rack is full loaded. The galvanized parts are tested by the salt spray test and the products will be not discolored in 15 minutes, which can guarantee the usage period over one year.
PCB Board Specification: 535X(120-460)mm side plate guideway, groove depth is 4.0mm, groove breath is 5.5mm, the pitch is 10mm, the material of the upper baseboard and bottom baseboard is the metal with adjustable screw fixation, it is the adjustable gear track design and and easy to operate. Surface Resistance:104-106Ω. It is divided with ordinary type and high temperature resistant type(130℃). Boundary dimension: 535×530×570mm, available for storing 50 pieces of PCB board.
Product Model | PCB Board Specification | Boundary dimension | Notes |
CS6683080 | 460X(50-400)mm | 400×460×563mm | Available for 50 pieces of PCB boards |
CS6683081 | 350X(80-250)mm | 355×315×580mm | Available for 50 pieces of PCB boards |
CS6683082 | 350X(50-250)mm | 355×320×563mm | Available for 50 pieces of PCB boards |
CS6683083 | 350X(50-250)mm | 355×320×563mm | Available for 50 pieces of PCB boards |
CS6683085 | 350X(50-250)mm | 355×320×563mm | Available for 50 pieces of PCB boards |
CS6683086 | 535X(50-390)mm | 535×460×570mm | Available for 50 pieces of PCB boards |
CS6683087 | 535X(120-460)mm | 535×530×570mm | Available for 50 pieces of PCB boards |
Product picture:
