Vibration Damper for Adss/opgw Cable Made in Haihong

vibration damper for adss/opgw cable

Composition: hot galvanized casting iron hammer, hot galvanized steel twisted wire, aluminum

alloy clamp, stainless steel bolts.
Purposes: to eliminate or reduce the vibration when the fiber optic cable operate under the influence of  kinds of factor, then protection of cables and fittings.
Features: using a typical Harrow design, the basic principles : dynamic absorbing energy, frequency protection range from 6Hz to 150Hz, and in this range it has four resonant frequencies.
Technical requirements: comply with GB / T 2336-2000 anti-vibration hammer technological conditions.
Order Information: Users must provide the following information for specific projects the company can make corresponding vibration programs:
a. line tower schedule.
b. topography, landforms (plains, hills, mountains, forests, across rivers).
c. Cable specification model and relevant parameters - diameter (mm), nominal tensile strength (N), unit weight (kg / m) and so on.
Damper Specifications Model and Parameter table:

Armor rod for anti-vibration hammer: In order to avoid the damage when anti-vibration hammer clamp gripping the OPGW cable, coupled with aluminum alloy armor rod, protection cable, at the same time the system play a role in anti-vibration .
Specifications Model representation: HXT-Length (mm )-**.
**-- On behalf of Cable diameter (mm).

 order  direction

When ordering product, customer should provide the cable diameter and advise if there are armour rods.

Factory and workshop
