high efficient industrial oil removal machine for sales

Specifications

The main function of YM series high efficient jet flow  air flotation purification machine (degreaser) is remove oil and suspended matter in the sewage, which is improved to be series air floation purification machine by our company using foreign technique. Its predecessor equipment is invented by American WEMCO on 1980 ,this equipment is rectangle tank, the entrance and exit of water is setup in both ends of tank, the top of tank install 4 motors ,this motors will drive respectively impeller in trough form into 4 grade aeration, both sides of flotation cell installed scraper used in scrape oil, then the motor drive the scraper to achieve the purpose of oil-water separation by scraping the flotation oil .

Our company import this technique in 1993,after digestive absorption, begin to produce the second generation Floating purification machine ,which solved the  original equipment ‘s shortcoming of Aeration bubble large particle size ,bubble scatter uneven,low removal rate of oil . our company  made a Comprehensive Analysis of operation condition to each spot in 2001,  then made technical transformation once again and produced the third generation jet flow air flotation machine, got good valuation from client.

The jet flow air flotation purification machine( degreaser) has widely used in each big coking plant and Oil Refinery in nationwide,it has obvious remove effect in dealing with Surplus ammonia, Phenol cyanide wastewater,tar in Washing-rich liquid, oil in discharge water of offsite, mainly solved the puzzle question of ammonia distillation tower and heat exchanger blocking constantly which will affect normal production.

The using effect of jet flow air flotation purification machine ( degreaser) in Petrochemical Industry is more obvious., such as the first factory of DaQing petroleum and other factory, Liaohe Oilfield, Dagang oilfield, Qilu Petrochemical,Fushun petroleum etc.

The treated wastewater can up to the emission standard of national regulation(special wastewater can dispose by dosing). This equipment especially win the bidding by defeating American Mcwong Air flotation machine in Beijing Yanshan Petrochemical sewage project .

Dozens of coking plants and iron and steel company,oil-field all adopt our company produced jet flow air flotation purification machine ( degreaser) at present, in application of flotation technique,our company’s bid rate above 90% in Engineering bid.

.Operating principle:

YM series jet flow air flotation purification machine ( degreaser) absorb air into water system by circulating water pump(jet pump) in jet flow manner, forming air water admixture , the air water mixed liquid pass dissloved air vessel respectively enter into 4  aeration regulator, then return equipment by release head, the bubble size processed by release head will be small ,make them adhere to floccule surface, thus separate the pollutant in water. The pollutant in different position of equipment will focus discharge into the under tank or mechanize clarifying tank after collected. The water after purify can be reuse ,air flotation purification machine has advanced jet flow dissolved air system, which realized multilevel  tandem type flotation, improve the removal rate of oil or suspended matter.

Technique Data :

 According to sewage ‘s variety and Emulsification degree , the oil removal rate of the exit sewage  emulsified fuel after multistage flotation can reach 70%-90%( if contain Soluble oil,emulsified oil can be dispose by dosing ),the removal of suspended can reach 50%-80%; the removal of COD can reach 50%,this series equipment’s disposal capacity is 10-800 CBM, its main performance index can achieved the international similar product level in the 1990s, leading position in china. Dispose medium temperature: 0-80 °C     Jet pump power: 380V, 50HZ

Model and parameters

Company Information



Qingdao Yimei environment project Ltd. is set up in 1988 , is located in maximal Chinese military affairs harbour base Jiao Nan City. Take up a field producing 15,000 square metres workshop building 36,000 square metres, have more than 130 treating machinery of all kinds. Be a Shandong Province environmental protection industrial association trustee member unit. Now have staff and worker 360 people engineers and technicians among them 72 people , be engaged in the environment project , environmental protection equipment design , fabrication mainly. Water treatment technological development , engineering construction , technical service and series of products of consumer need. The company owns the well experienced engineer, specialized production big and powerful base , advanced fabrication equipment. May be that the consumer provides the first-rate product and the special field consulting about and serve. The long range concentrates efforts on environmental protection cause investing in construction , complete sets of equipment turn out and the project are always contracted
