Home > Products > TLS Limit Switch > Limit SwitchTLS-131
Limit SwitchTLS-131
Negotiable
/ Piece
100 Pieces(Min. Order)
- NINGBO
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | TMAZTZ | |
| Model Number | TLS-131 |
Product Description
Specifications
Specialized manufacturer of Limit switch, Micro switch,foot switch with 20 years experiencesTLS-131 Limit Switch
1.Item no: TLS-171
2.Normative reference:IEC60947-5-1
3.Vibration resistance:comply with IEC60068-2-6
4.Shock resistance: comply with IEC60068-2-27
5.Degree Of Protection:IP64, comply with IEC60529
6.Mechanical life:15,000,000 times
| Model | TLS-101/301 | TLS-103/303 | TLS-111/311 | TLS-121/321 | TLS-127/327 | TLS-131/331/191/391 | TLS-161/361/371/181/381 |
| Trggering | At the end | 30°convex trigger | 30°convex trigger | 30°convex trigger | 30°convex trigger | 30°convex trigger | Any moving part |
| Max trggering speed | 0.25m/s | 0.25m/s | 0.25m/s | 1.3m/s | 0.25m/s | 1.3m/s | 1.3m/s |
| Max trggering force | 700g | 700g | 700g | 500g | 700g | 500g | 150g |
| Min restoring force | 200g | 200g | 200g | 100g | 200g | 100g | 50g |
| Wiring | Cable | sizeØ12, | each | terminal | can hold | conductors of 2 | mm at most |
