High speed Fine Wire Drawing Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	HONTA
Model Number	HT-22DTS		Usage	Drawing

Fine wire drawing machine with Automatic spoolers:

Features:

u Multi-zone DC annealing, HMI+PLC control, more human oriented;

u It can change spooler automatically without machine stop; therefore, it improves efficiency and saves labor;

u Special traverse and spooler change mechanism can ensure a high success rate of switchover and machine stability.

u Wires are loaded in ABS spools, which can meet requirements of the next process and lower costs.

-------------------------------------------

Technical Specification:

Machine type	HT-22DTS	HT-24DTS	HT-24DTS-A
Material	Cu		Al, Al-alloys
Machine speed	1800m/min
Inlet dia.	1.20-1.60mm	0.50-1.20mm	0.50-2.30mm
Finished dia.	0.15-0.60mm	0.08-0.40mm	0.15-0.70mm
No. of dies.	Max.22	Max. 24	Max. 24
Capstan dia.	159mm
Annealing current	Max.600A	Max. 300A	Max.400A
Annealing power	Max. 36kw	Max. 24kw	Max. 30kw
Bobbin standard size	180-30029030(37)mm, ABS plastic bobbin
Spooler charge system	Auto change spooler without stop when spooling to preset length.
Main capacity	60KVA	40KVA	55KVA
Machine dimensions	320017001800mm

-----------------------------------------------

Finished Products

Fine wire drawing machine with Automatic spoolers:
