2015 Hot Sale Andesite Rock Crusher

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Keelung/ Taiwan
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Cone Crusher
Application	stone crushing	Motor Type	AC Motor
Power(W)	125-375hp	Capacity(t/h)	60-650
Place of Origin	Taiwan, China	Brand Name	CMC
Model Number	Refer to list below	Certification	CMC
Warranty	one yeatr	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

CMC PA Series High Performance Cone Crusher Combines Speed, Stroke and Cavity Design Perfectly and Can Provide Higher Capacity and Better Product Quality

U.S. patent No.: 5915638/6520437

Taiwan patent No.: 132720/143974

Japan patent No.: 3046502

European Patents No.:2345867

China Patents No.:349167

Vietnam Patent No.:H199900

Advantages:

♦ Can reach at least 90% of Metso the same HP cone model

♦ High capacity

♦ Cubic product shape and high yield with desired fines

♦ Large crushing ratio
♦ Low operation and wear cost due to less over size

♦ Easy maintance and operation by PLC control system and self tighten Mantle & Concave

♦ Provide mutiple cavity from extra fine to extra coarse for different application eg. sand crushing... coarse crushing...etc

Features:

♦ New generation high performance cone with advantages of high capacity, cubic product shape high yield with desired fines

♦ High rotation speed (much higher than hydraulic cone & spring cone), and large eccentric throw. This combination has providing revolutionary result in providing higher capacity & superior product quality

♦ Support structure is minimized due to low profile, compact structure and rubber damper crusher chassis design

♦ Equipped with fully hydraulic system. Therefore operation is very easy; especially tramp iron release is very quick and sensitive

♦ With PLC control system (PLC & touch monitor is Siemens brand.)

♦ Self tighten Mantle & Concave

Specifications:

Model

Closed Side Setting (mm)

P1A

T/H

42~52

47~57

52~66

57~76

66~85

71~90

76~95

80~104

95~133

P2A

T/H

86~116

116~146

136~176

146~186

156~196

166~216

186~231

206~246

P3A

T/H

110~136

146~180

176~216

196~236

216~256

226~276

246~316

296~376

246~436

P4A

T/H

136~171

180~226

221~276

250~316

270~340

290~366

320~426

356~486

406~556

460~626

Operation Video
