SXHF 20L bottle filling line, water filling line, barrel filling line

Specifications

1 20L bottle filling line
2 20L water filling line
3 barrel filling line

4SUS 304

APPLICATION:

It is especially used for 5 Gallon barrel pure water washing, filling, capping production line.

CHARACTERISTICS:

The parts with touch water adopt high-quality stainless steel. The cylinder gear runs smoothly and the fixed position is correct. It adopts inserting-type washing technology to remove washing blind angle.

Product Description
1) The machine combines the functions of rinsing, filling and capping.
2) Whole body of the machine is made of stainless steel with anti-corruption and easy-rinsing.
3) The main electrical parts are from Siemens and Omron.
4) Pneumatic parts are imported.
5) Rinsing nozzles adopt American spraying system technology.
6) With compact structure, high efficiency and stable operation, this is a highly automatic unit with machine, electricity and pneumatics in one machine.

Filling:The cleaned bottles would be turned over with the running of chain,then falling into the bottle

carrying chair pushing cylinder pushes the chair go ahead with the cleaned bottle the filling head,

the filling time and the filling volume can be adjusted by on the operation panel

Fixing and pressing cap:after the filling steps,the full filled bottle will be pushed by the following bottles to the cap through,all the caps would be supplied by the cap ordering monitor after being laid the caps, the following bottles pushing these two bottles to the cap pressing cylinder the cap will be pressed firmly by the cylinder After all of these steps the products will go to the conveyor then to the packing part

Production line:the full production line include the cap remover,outer and inner automatic bottle washer upload system,washing,filling and capping machine,lamp checking,heat shrinking machine,bottle lift machine
