ML12 TWO COLOUR DRINKING STRAW MACHINE EXTRUDER

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Pipe
Plastic Processed	PP	Screw Design	Double-screw
Place of Origin	Jiangsu, China	Brand Name	Marrow
Model Number	ML12

Product Description

Specifications

capability:800~1200pcs/min
straw diameter:3~12mm
raw material:PP

ML12 TWO COLOUR DRINKING STRAW MACHINE EXTRUDER

DESCRIPTION

Model ML12 is a tube extrusion line, composed of extruder and die, size setting and water cooling unit, haul-off unit, rotary cutter unit, The series machines can produce all kinds of drinking straw,spiral strip straw,from one color to two color , medical pipe, all the machine’s controls base with the control elements ergonomically adapted to permit easy operation.

SPECIFICATIONS

Model		ML12
Feature	Material	PP
	Color	2
	Straw diameter	φ3.5 – φ12 mm
	thickness	0.15 - 0.35 mm
	Straw length	120 – 300 mm
	Stripes	Straight or Helical
	Capability	400 – 1800 pcs/min
	Extruding output range	20 – 35 kgs/hr
Extruder	Screw diameter	φ50 mm×1 φ25 mm×1
	Screw L/D	28 : 1
	Main driving motor	11 Kw ×1 0.75Kw ×1
	Automatic thermo-controller	8 sets
	Heating power	11.63 kw
Water tank	Forming device	1 set
	Vacuum Pump motor	1.1 kw(choose)
	Water storage tank	3400 mm
	Base frame material	Steel stainless
	Blow dry device	1 set
Take up & Cutting Unit	Take up unit	1 set
	motor	0.75kW×1(VFD)
	Cutting knife unit	1 (Two end cut together, with slot cutting blade)
	motor	0.75kW×1(VFD)
	Digital counter	1 set
Others	Air compressor	1.5kw(choose)
	Dimension LxWxH	8×1.2×1.6 m
	Machine weight	2300 kgs
