Home > Products > automatic stretch blow molding machine > Blow Moulding Machine for Bottle up to 2L
Blow Moulding Machine for Bottle up to 2L
- NINGBO
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | Other, PET, PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | JUNENG | Model Number | JN-4000 | |
| Voltage | 380v | Power(W) | 44 | |
| Dimension(L*W*H) | 4.8x2.2x2.2 | Weight | 6000KG | |
| Certification | CE | Warranty | 1 year, 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Taizhou Huangyan JUNENG machine&mould Co.,LTD
PET blow molding machine
Products Feature:
- High safety. high speed with high efficiency.
- manual saving, one man is enough for operation the machine.
- Stable performing with easy maintaining.
- Imported PLC controlling and man-machine interface computer.
- japan Omron inspection sensor.
- Adopt the new type double bend arm and the four rod-clamping structure(won the patent): Cross direction; Middle mould board is move parallel; the distance between two mold board is adjusted by the chain wheel. Thus, the clamping force is very strong.
- Power saving design that can increase your profits.
- Segregate type air controlling system, which is designed for avoiding waste pollution.
General Specifications:
JN-4000 Specifications | |||
| Model | Unit | JN-4000 |
Clamping System | Number of cavity | cavities | 4 |
calmping unit | KG | 42000 | |
mold stroke | mm | 90 | |
stretch stroke | mm | 250 | |
Bottom stroke | mm | 30 | |
Cavity pitch | mm | 76.2 | |
heating pitch | mm | 76.2 | |
Number of holder | PCS | 86 | |
Container | ntainer volume | ltr | 0.6 |
Max. neck diameter | mm | 38 | |
Max.prefrom height | mm | 140 | |
ntainer diameter | mm | 110 | |
ntainer height | mm | 250 | |
theoretical output | B.P.H | 4000 | |
Electrical System | heating oven | UNITS | 8*7 |
box*channel | |||
Number of lamp | pcs | 56 | |
heating power | KW | 67.2 | |
installed power | KW | 75 | |
voltage | Voltage | 220v/380V/3phase | |
Air System | operating pressure | kg/cm2 | 7 |
blowing pressure | mpa | 3.5 | |
high pressure air consuming | L/min | 4200 | |
power | KW | 44 | |
| temperature | °C | 10-15 |
pressure | Mpa | 0.3-0.5 | |
flow rate | L/min | 80 | |
heating power | HP | 6 | |
Machine | machine dimension | M | 4.8*2.2*2.2 |
machine weight | KG | 6000 | |
Production Process:
Take bottle in :
Mould:
Our customers:
Contact us:
Contact Us
- Taizhou Huangyan Juneng Machine And Mould Co., Ltd.
- Contact namecharleen zhang Chat Now
- Phone0086-576-89186109
- Addressno.626,daqiao road ,huangyan,taizhou,zhejiang ,china, Taizhou, Zhejiang
