Home > Products > BOPET Film > polyester film for metallizing application
polyester film for metallizing application
- 80000 Metric Ton / Metric Tons per Month
- zhangjiagang china jiangyin china shanghai china
- T/T L/C D/P D/A
You May Like
Product Details
| Material | PET | Type | Stretch Film | |
| Usage | Other, various electronic and electrical applications | Feature | Moisture Proof | |
| Processing Type | Casting | Transparency | Translucent | |
| Place of Origin | Jiangsu, China | Brand Name | JADE | |
| Model Number | MA |
Product Description
Specifications
1)High tensile strength2)Good toughness
3)Excellent chemical resistance
4) Electric insulation
Specifications:
Thickness(μm):06~75
Width(mm):380~2000
Roll ID(mm):76mm or 152mm
Characteristic feature:
1)High tensile strength
2)Good toughness
3)Excellent chemical resistance
4) Electric insulation
Usage:
Be used for electrical insulation, such as slot insulation, interphase insulation and liner insulation in
electric motor, wrapping insulation for coils and cables, as well as producing insulation flexible
composite material.
Typical property values:
| Item | Units | Typical values | Test method |
| Nominal thickness | um | 25 | DIN 53370 |
| Thickness Deviation | % | ±1.5 | ASTM D 374 |
| Tensile strength(MD/TD) | MPa | 210/210 | ASTM D 882 |
| Elongation(MD/TD) | % | 160/150 | ASTM D 882 |
| Heat shrinkage(MD/TD)150°c,30min | % | 1.6/0.3 | ASTM D 1204 |
| Haze | % | 3 | ASTM D 1003 |
| Gloss | % | 125 | ASTM D 2457 |
| Surface wetting tensions corona discharge | Dyne/cm | 52 | ASTM D 2578 |
| No corona discharge | 44 | ||
Note: MD=machine direction,TD=transverse direction. This specification is typical product information.The results should only be interpreted as a general guide to material properties,not as a guarantee.Certificates of analysis are available upon customer request. | |||
RAW MATERIALS
MACHINE
PACKAGE
USE
Contact Us
- Jiangsu Sanfangxiang Group Co., Ltd.
- Contact nameGeorge Xue Chat Now
- Phone86-510-86229006
- AddressZhouzhuang Town, Jiangyin City, Jiangsu Province. China, Wuxi, Jiangsu
