MX wet and dry type cable wire recycling equipment

  Cable wire recycling equipment is now divided into two types One is dry type recovery equipment, the advantage of handling a large amount of copper, after processing the copper is dry, but poor effect for recycling fine electric wire ,there are some plastic inside copper; another separation is wet type water recycling equipment, the advantage is recycling is better, the recovery is relatively high, but the yield is low, fees artificial, recycled copper is wet and copper color easy changed.

Jiangxi Mingxin developed wet and dry type cable wire recycling equipment dual use copper-rice machine to solve the above problems, the first dry separation and then by wet separation, the larger copper particles selected automatically by dry separation, the hair copper wire is automatically selected by wet separation, the recovered higher quality copper ( price than the water-separation higher about 200USD~300USD), but also to achieve a better recovery rate (over 99%), the entire process automatically, you can use less labor to achieve higher production.

Application and performance
MX- Wet and Dry type cable wire recycling equipment (Cable granule separation equipment)- To process waste cable and wire. Get the copper separated from waste cable and wire through crushing and gravity separation process, no copper at plastics and no plastics at copper. No incineration and pollution. It is in compliance with EHS standard, no harmfulness to workers, eco-friendly solution for waste recycling.
Automatic process, stable performance, easy for operating, easy to maintenance, high recycling rate. Patent number:  201120415640.0

Patent certification

Wet and Dry type cable wire recycling equipment
The system applies for all types of cables, such as: communication cable, flower wire , fire lines , bus lines , single-branch , multi-branch, wool silk lines ,  miscellaneous cables, automotive cables, with high recovery rate, easy operation and auto control system. Typical system can process 500 kg cables per hour, and its capacity can be adjusted accordingly to the output device configuration to meet higher demand.
The process is from dry separating to wet separating. Larger particles of copper are automatically processed through dry separating, thin copper wire is automatically through wet separating. Copper recovery rate can reach 99.9%.  Automatical system is also available to achieve less labor cost.


Model
Double
Capacity(kg/h) : 800-1000
Full production line total power(kw) : ≥120kw
Separation efficiency :≥99%
Equipment dimensions(L*W*H)mm:22000*10000*3200

Single:
Capacity(kg/h) : 300-500
Full production line total power(kw) : ≤60kw
Separation efficiency :≥99%
Equipment dimensions(L*W*H)mm:22000*5000*3200

Specifications

1.      Automatic control, stable performance
2.      easy for operating, easy to maintenance
3.      high recycling rate
4.      get through ISO9001
5.      All kinds of cable/wire available
6.      first dry separation then wet separation , can separate thoroughly

Packaging & Delivery

Packaging Details: normal packing
Delivery Detail: 15-25 days after advanced 30% T/T

The system mainly consist of :
Infeed conveyor belt; Intelligent cable shredder ;Conveyor Belt; Copper Granulator ;Vibrating air separator ; De-dusting system ;
 Hydraulic separation equipment.

Function of each component :
Infeed conveyor belt : feeding the waste cables to the system .
Intelligent cable shredder : shred the cable into pieces and make the steel ready to be separated .
Conveyor Belt: deliver the cables between equipment.
Magnetic separator : separate the steel from the cable pieces .
Copper Granulator : crush the pieces into fine uniform sized granule, allowing the copper to separate from plastic .
Vibrating air separator: Separate the larger particles of copper.
De-dusting System:remove dust from the system to make high quality output .
Hydraulic separation equipment:Thin copper wire is automatically through wet separating .
.

Dry and Wet Cable Wire Recycling Machine
