Home > Products > Infrared Thermometer > Infrared Thermometer
Infrared Thermometer
- Shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Model Number | HT-822 |
Product Description
Specifications
Infrared ThermometerPrecise non-contact measurements,
Automatic Data Hold & Auto power off,
Backlit LCD display.
Infrared Thermometer
Main Function
1.Precise non-contact measuremen
2.Built-in laser pointer
3. Automatic selection range and Resolution to 0.1ºor 1º
4. °C/°F switchable buton
5. Automatic Data Hold & Auto power off
6. The meter at 8 inches away measure 1 inch target
7. Backlit LCD display
Specifications
General specifications
DISPLAY | 3-1/2 digit (1999count) LCD with backlighting |
MEAS. RANGES | -50.0°C to 550°C(-58.0°Fto 1022°F) |
SAMPLE RATE | 2.5 times/second. |
POLARITY | Automatic (no indication for positive polarity); Minus (-) sign for negative polarity. |
EMISSIVITY | 0.95 fixed value |
FIELD OF VIEW | D/S = Approx. 8:1 ratio (D = distance, S = spot) (Has 90% encircled energy at the focal point) |
DIODE LASER | Output <1mW, Wavelength 630~670nm,class 2 (II) Laser product |
SPECTRAL RESPONSE | 6~14um |
POWER OFF | Automatic shut off after 7 seconds, approx. |
OPERATING TEMP. | 0°C to 50°C (32°Fto 122°F) |
STORAGE TEMP. | -20oC to 60oC(-4oF to 140oF) |
RELATIVE HUMIDITY | 10%~90%RH operating, <80%RH storage |
POWER SUPPLY | 9V battery, NEDA 1604A or IEC 6LR61, or equivalent |
WEIGHT | 130g. |
SIZE | 826x 46 x 160mm |
Infrared thermometer specifications
Range (Automatic selection 0.1 oC/ 1oC) | Resolution | Accuracy
| |
-50.0oC to 550 oC | -50.0oC to -20.0 oC | 0.1 oC | + 5 oC; |
-20.0oC to 550oC | ± 2% of reading or ± 2ºC; | ||
Range (Automatic selection 0.1 °F/ 1°F) | Resolution | Accuracy | |
-58.0°Fto1022 °F | -58.0 °F to -4.0 oC °F | 0.1°F | + 9 °F; |
-4.0 °F to 1022 °F | ± 2% of reading or + 4 °F; | ||
