Home > Products > New Products > STA-High Purity Alumina Ceramic Foam Filter
STA-High Purity Alumina Ceramic Foam Filter
- shanghai qingdao
- T/T Credit Card
You May Like
-
Alumina Titanate Riser Tube Ceramic Riser Tube
-
Factory Price :alumina Titanate Riser Tube
-
Wear Resistance Aluminium Titanate Ceramic Riser Tube
-
ZhengZhou STA Aluminium Titanate Ceramic Riser Tube For Aluminum Industries
-
STA Heat Resistant Aluminum Titanate Riser Tube
-
STA Aluminium Titanate Riser Tube for Aluminum Die Casting
Product Details
| Place of Origin | Henan, China | Type | Ceramic Parts | |
| Application | Industrial Ceramic | |||
| Model Number | STA-ACF01 | Brand Name | STA |
Product Description
Specifications
Specifications:1. SiC Foam Filter
2.Alumina Foam Filter
3Zirconia Foam Filter
4.Good resistence for high temper
STA-High Purity Alumina ceramic foam filter
Alumina Ceramic foam filter is mainly used for filtration of aluminium and aluminium alloys in foundries and cast houses. With their excellent thermal shock resistance and corrosion resistance from molten aluminum, they can effectively eliminate inclusions, reduce trapped gas and provide laminar flow, and then the filtered metal is significantly cleaner. Cleaner metal results in higher-quality castings, less scrap, and fewer inclusion defects.
Alumina ceramic foam filter has the advantages of high prorosity, low loss of thermal shock, high mechanical strength at normal and high temperature, large specific surface, good chemical stability and excellent filtering functions of screen, filtering residum collection and absorption especially for tiny impurity of 1~10um.
Physical and Chemical Properties
Type | Alumina CFF | Silicon carbide CFF | Zirconia CFF | Magnesia CFF |
Material | Al2O3 | Sic | ZrO2 | MgO |
Applied temperature | ≤1200 º C | ≤1500 º C | ≤1700 º C | ≤1100 º C |
Color | White | Grey black | Yellow | Yellow |
Bulk Density | 0.35~0.55g/cm3 | 0.45~0.65g/cm3 | 1~1.5g/cm3 | 0.5~0.7g/cm3 |
Bore Density | 10~60PPI | 10~60PPI | 10~60PPI | 10-60ppi |
Porosity | 80~90% | 80~90% | 80~90% | 80-90% |
Bending Strength | 0.6Mpa | 0.8Mpa | 0.8-1.0Mpa | 0.6Mpa |
Compression Strength | ≥0.8Mpa | ≥1.0Mpa | ≥1.5Mpa | ≥0.8Mpa |
Thermal Shock Resistance (1100 º C ~ Room Temperature) | Not break after 6 times thermal shock testing | |||
Application | Molten Aluminum and Alloy | Molten Iron and Alloy | Molten Stainless Steel, Alloy and other metal in precision molding | Molten magnesium and its alloys |
Specifications
Alumina ceramic foam filters are available in a wide range of sizes and in
several standard shapes and pore sizes.
1.Round Shape (mm):
D*H D=30~200mm H=5~20mm
2. Square and Rectangular Shape (mm):
L*W*H
L=40~500mm W=40~500mm H=10~50mm
Various sizes are available on your request.
Product photos
