High Temperature NBSIC Sic Ceramic Thermocouple Sheath of Factory Price
- China Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
STA High Temperature Sic Ceramic Thermocouple Sheath of Factory Price
-
ZhengZhou STA Top Quality Sic Ceramic Sheath for Alumina Liquior
-
STA High Performance Silicon Carbide Ceramic Sheath for Alumina Liquior
-
ZhengZhou STA High Temperature Silicon Carbide Sheath for Alumina Liquior
-
ZHENG ZHOU STA Si3N4 Silicon Nitride Thermocouple Tube for Protection
-
Factory Price High Temperature Refractory SiC Silicon Carbide Tube
Product Details
| Place of Origin | Henan, China | Type | Ceramic Tubes | |
| Application | Industrial Ceramic | Model Number | STA-SIC-30 | |
| Brand Name | STA |
Product Description
STA high temperature NBSIC sic ceramic thermocouple sheath of factory price
Silicon Nitride Bonded silicon carbide sheath
Si3N4 bonded SiC ceramic refractory material, is mixed with high pure SIC fine powder and Silicon powder, after slip casting course, reaction sintered under 1400~1500°C. During the sintering course, filling the high pure Nitrogen into the furnace, then the silicon will react with Nitrogen and generate Si3N4,.Si3N4 bonded SiC material is composed of silicon nitride (23%) and silicon carbide(75%) as main raw material,mixed with organic material,and shaped by mixture, extrusion or pouring,then made after drying and nitrogenization.
1.Technical performance
2.Standard size:
The diameter of Si3N4 bonded SiC thermocouple protection tube is Φ12-80mm,length is 1600 mm.It can be usded in high temperature kiln furnace and all kinds of atmosphere.It also can be directly used in all kinds of melted liquid.
| Common size of the NBSIC | ||
| Outer diameter | Inner diameter | Length |
| 13 | 10 | 500-1000 |
| 16 | 8-10 | 300-1000 |
| 20 | 12 | 300-1200 |
| 25 | 14-15 | 1500 |
| 28 | 16-20 | 300-1200 |
| 30 | 10-20 | 1500 |
| 35 | 25 | 300-1250 |
| 40 | 25-28 | 300-12000 |
| 50 | 25 | 300-1200 |
| Remarks:the protection tubes can be customized | ||
Application:
As a pipe of transmitting the liquid aluminum for the automobile hub casting, the Silicon Nitride Riser Tube is widely used in the aluminum smelting industry, petroleum chemical industry, ceramic industry and electronics industry
