Home > Products > Outdoor Signage Printer > Docan High-resolution UV Printer Flatbed Roll to Roll 2.5m Width, Flat Glass uv Machine
Docan High-resolution UV Printer Flatbed Roll to Roll 2.5m Width, Flat Glass uv Machine
US$ 40,000 - 130,000
/ Set
1 Set(Min. Order)
- Shanghai
- T/T
You May Like
-
Docan 3*2m Advertising Billboard uv Flatbed Printer of High Resolution & High Speed
-
Docan Uv Flatbed Glass Printer M6 With Resolution up to 1440*1440
-
Docan Affordable Wide Format Printer Docan M6, Flat Glass Printer for Sale
-
Digital Flex Banner Printing Machine/roll to Roll Printing Machine
-
Digital Advertising Signage uv Printer/uv Flatbed Printer
-
3.2m Large Format Sign Graphic Image uv Printer/ Roll to Roll Printer
Product Details
| Plate Type | Flatbed Printer | Place of Origin | China | |
| Brand Name | Docan | Model Number | FRT3116 | |
| Usage | Bill Printer, Label Printer, Paper Printer, Other | Automatic Grade | Automatic | |
| Voltage | 220v | Gross Power | 8kw | |
| Dimensions(L*W*H) | 5.13*3.16*1.44m | Weight | 2620kg | |
| Certification | CE, CCC; ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Docan FRT3116 UV printer
FRT3116 UV Flatbed Printer is a kind of large inkjet printer mainly used to print images on flatbed material and flexible materials due to that it combines the roll-to-roll function with the sheet-to-sheet, The images designed on the computer can be printed out as their original shape
The maximum printing size of this printer is 3.1 x 1.5m for the rigid mateials and 2.5m printing width for the flexible materials
Features of Docan FRT3116
Our FRT3116 UV flatbed printer can print images on all kinds of flatbed materials and flexible materials, such as glass, acrylic, PVC foam board, ceramic, aluminum composited panel, corrugated board, aluminum sheet, metal,wave board, wood , MDF,ceiling, banners, vinyls, wall paper, timely paste,canvas, leather,etc.
Special pre-treatment to materials is unnecessary.
The maximum printing material thickness is 100mm.
The printing effect is very good and the images are firmly printed on the panels, This ensures that the printing effect can be well preserved for a long time without fading(indoor for 10 years and outdoor for 3 years.)
Basic Characteristics of FRT3116
| Model | FRT3116 |
| Catagory | UV Hybrid Printer |
| Print Technology | Drop-on-demand Piezo Electic |
| Nozzle Technology | Piezoelectric Inkjet |
| Print head type | KM-512-14PL/KM-1024-14PL/RICOH GEN5 |
| Print head controls | Print head temperature and voltage are software adjustable |
| Ink Characteristics | UV curing ink |
| Ink Reservoir | Refillable on the fly while printing/ 1000ml |
| Drying system | UV lamp |
| Rip software | Photoprint/ Onyx/ Caldrea |
| Color Management | Icc Based Color, Curves Adjustment, Density Adjustment |
| File Format | Tiff, Jpeg, Postscript 3, Eps and Pdf |
| Power supply | 50/60hz 220v ( 10%) >30A |
| Operation Environment | Temperature 20℃ to 28℃ degrees |
| Humidity | 40% to 60% |
| Product Model | Docan FRT3116 |
| Printing Size | 3.1 x 1.5m for the rigid materials, and 2.5m printing width for the flexible materials |
| Media thickness | 1-100mm |
| Nozzle Number | 4/5/6/7/8/10/12/15/16pcs |
| Resolution | 360dpi*360dpi 360dpi*720dpi |
| 720dpi*360dpi 720dpi*720dpi | |
| 720dpi*1440dpi 1440dpi*1440dpi | |
| Printing speed | In Draft mode up than 58 sq.m/h (8 heads) |
| In Standard mode up than 42 sq.m/h ( 8 heads) | |
| In High resolution mode up than 34 sq.m/h (8 heads) | |
| In Super resolution mode up than 26 sq.m/h ( 8 heads) | |
| Colors | 4 colors(C M Y K) or 6 colors(C M Y K Lc Lm). White & varnish can be optional |
| Outdoor life | 3 years(use Docan ink) |
| Dimensions | 5.13*3.16*1.44m |
| Weight | 2620KG |
