Advertisement Printing Machine 3.1*1.6M, PVC Banner Hybrid Printer FRT3116/ Roll to Roll Printer

Product Application

This machine is our UV Flatbed Printer, also known as multiple UV printer. Using the UV ink it can print excellent images on various rigid medias, such as glass, acrylic, wood, PVC foam board, KT board, MDF, alumimum, cellphone case, ceramic tiles, and so on. Also, it offers various ways of printing the white color. It can print the three-layer spot colors which means it can print color-white-color at one time!

The printheads can be Ricoh Gen5/ KM1024/ KM512. The printing colors can be LcLmYMCKW, and White is optional!

Main Features

 Simple structure in linear type ,easy in installation and maintation.

 Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

Excluding the use of VOC (Volatile Organic Compounds) in the UV curable ink. The ink is environmental friendly and no smell
With advanced Automatic Height Detector which can detect the material thickness and find a good height position for best quality printing
Drawer-type UV lamp cassette makes it easy to replace the UV lamp
Equipped with Japanses THK mute guide rail
Carriage is with a crash sensor with high sensitivity to ensure that the printhead will not be accidentally damaged
The white ink catridge is with the automatic stiring and circulation system, which avoids the clog of the White printhead.
Easy operation menu. User-friendly

Machine Parts

Name: Guide line

Brand: THK

Original: Japan

Main Features

Name: Toweline
Brand: IGUS
Original: Germany

Machine Parts

Name: UV lamp
Original: UK

Main Features

Name:  Y axis screws
Original: Taiwan
